Relation to command/query API

The enfore platform's core API is a command/query API that is based on the CQRS pattern (see Martin Fowler - CQRS). That API provides access to the full MetaCompany domain model. As the MetaCompany model is designed to cover almost any conceiveable use case, the API is very fine-grained and rather complex.

Additionally, the MetaCompany API uses a proprietary definition language and custom tooling for code generation. Both of which cannot easily be used by external developers.

To provide middleware developers with an easy-to-understand, easy-to-use API for integration, we decided to provide the Staff & Access Rights API as an API specialized for Staff & Access Rights workflows/uses cases and to use industry-standard technologies for the definition of the API.

Technology and tooling

The enfore API for integrations is being defined using the OpenAPI specification.

The API will be RESTful and follow industry-standard best practices such as Zalando - RESTful API Guidelines.

Cross-cutting concerns

Cross-cutting concerns affect many of our APIs.

Login Flow

For authorization, we use HTTP basic authentication to authenticate and then give an access token to the APIs.

The access for a given application to various APIs and organisations at the moment cannot be managed by the end-user and are instead managed by the Enfore team. Similarly, application creation is managed by the Enfore team.

Once an application is created and has permissions for an organization, a secret key is generated.

Get Organisation specific access token 'org-access-token'

Calls to the authorize endpoint can be made via the Basic authorization scheme. For this, you will need to make a GET call to the /authorize endpoint with an Authorization header that contains the text Basic followed by Base 64 encoded app-name:secret pair.

For example, if your app-name is myapp and secret is mysecret, you will attach the header with value Basic bXlhcHA6bXlzZWNyZXQ= where bXlhcHA6bXlzZWNyZXQ= is the Base64 encoded string containing the text myapp:mysecret.

Now you can obtain an org-access-token for the organisation on behalf of which you would like to make calls to our APIs.

When the org-access-token expires, you can repeat the same process to get a new one. Here is an example call for the above request:

curl -X GET \
  https://external.apis.enfore.com/auth/authorize/<organisation-id> \
  -H 'Accept: */*' \
  -H 'Authorization: Basic <base64 encoded app-name and secret>'

The API will then respond with an org-access-token that is valid only for the given organisation ID of which was provided in the request (note: take a look at organisation-id variable in the path):

{
    "accessToken": <org-access-token>
}

Make API calls

Once you have an org-access-token (specific to the organisation), it can then be used to make the calls to an API via Bearer Authorization header.

Here is an example for the ERP invoices API (Note and must be filled in):

curl -X GET \
  "https://external.apis.enfore.com/erp/org/<organisation-id>/invoices?from=2019-02-13T00:04:00.000Z&to=2020-05-13T23:59:00.000Z&limit=10&offset=0" \
  -H 'Authorization: Bearer <org-access-token>'

Webhooks

Key data

This section covers key data elements used by enfore that are used across multiple APIs.

Platform-defined Tags

Assortment Tags

Assortment tags control what sales channel a product is "listed on". The enfore platform allows users to assign any number of such tags to each product and to each sales channel. A product is considered listed on a sales channel when the intersection of the product's and the sales channel's assortment tags is not empty.

Most assortment tags will be defined by the organization itself and must thus be created by the user via the client UI or via API.

The enfore platform defines only one platform-level assortment tag. This "Default" assortment tag is automatically suggested to user when creating a new product or sales channel via the enforePOS UI. This causes all newly created products to automatically be listed on all newly created sales channels when the user creates them via the enforePOS UI and does not manually assign other tags. Note that the default tag is not automatically assigned when creating products or channels via the API.

The ID of the "Default" assortment tag is: 548c522b3dbfea7cad435741

The full AssortmentTagReference for the "Default" assortment tag is:

{
    "@type": "AssortmentTagReference",
    "scope": "PLATFORM",
    "id": "548c522b3dbfea7cad435741"
}

Production Tags

Production tags control what processing location a product can be "produced by". The enfore platform allows users to assign a single such tag to each product and one or multiple such tags to each processing location. A product is considered to be "produceable by" a location when the product's production tag is contained in the location's list of production tags.

Most production tags will be defined by the organization itself and must thus be created by the user via the client UI or via API.

The enfore platform defines only one platform-level production tag. This "Default" production tag is automatically suggested to user when creating a new BTO product or processing location via the enforePOS UI. This causes all newly created BTO products to automatically be producable by all newly processing locations when the user creates them via the enforePOS UI and does not manually assign other tags. Note that the default tag is not automatically assigned when creating products or locations via the API.

The ID of the "Default" production tag is: 6139c6e23b1750b9f9963ede

NOTE: Production tags are not yet exposed via API.

Storage Tags

Storage tags control what storage locations a product is "associated with". Associating a product with a storage location is required for the location to be able to hold stock for the product as well as for recording manual stock modifications for the product/location pair. The enfore platform allows users to assign a single such tag to each product and one or multiple such tags to each storage location. A product is considered to be "associated with" a location when the product's storage tag is contained in the location's list of storage tags.

Most storage tags will be defined by the organization itself and must thus be created by the user via the client UI or via API.

The enfore platform defines only one platform-level storage tag. This "Default" storage tag is automatically suggested to user when creating a new inventory product or storage location via the enforePOS UI. This causes all newly created inventory products to automatically be associated with all newly storage locations when the user creates them via the enforePOS UI and does not manually assign other tags. Note that the default tag is not automatically assigned when creating products or locations via the API.

The ID of the "Default" storage tag is: 548c522b3dbfea7cad435742

The full StorageTagReference for the "Default" storage tag is:

{
    "@type": "StorageTagReference",
    "scope": "PLATFORM",
    "id": "548c522b3dbfea7cad435742"
}

Introduction (Spec)

This documentation describes the high-level architecture of the enfore Contacts-API.

The enfore Contacts-API is provided by the enfore platform to allow creating, reading and updating of contacts with their information.

The API consists of multiple modules that handle

• Individual Contacts
• Professional Identities of Individual Contacts
• Roles of Individual Contacts
• Organization Contacts
• Roles of Organization Contacts
• Customer Lists
• Placeholder Customers

Introduction (Spec)

This documentation describes the high-level architecture of the enfore ERP-API.

The enfore ERP-API is provided by the enfore platform to be convenient to use for ERP use cases in the "Retail" vertical, for example when integrating with an external ERP system such as SAP or Dynamics.

The API consists of multiple modules that allow

• import of master data for sales items, staff members and other business objects
• notification about and querying of invoice data, credit memo data and other business information

The exact set of modules and their capabilities will evolve over time, the initial API version will only support a very limited set of use cases.

Use cases

The aim of the ERP-API is to be useful for implementing use cases related to ERP, specfically in the "Retail" vertical.

Initially, the API will only support a small set of use cases:

• Import and update of sales item master data
• Notification about and fetching of invoice information

Import and update of sales item master data

A main use case for the ERP-API is the import and update of sales item master data. The use case assumes that the external system (e.g., SAP, Dynamics) has ownership of the data and that the enfore platform is subordinate to the external system.

Therefore, when an update request conflicts with a change made on the enfore platform's side, the enfore-side change will be overruled by the external change.

Notification about and fetching of invoice information

Another core use case is based on the usage of the enforePOS devices as a cash registers. Sales performed via the enforePOS devices result in invoice data being generated in the enfore platform (cf. MetaCompany "Ledger" module). The invoice data generated in the enfore platform must then be copied into the external ERP system.

For that, the ERP-API will provide the functionality to subscribe to an "invoice data available" event as well as a way to fetch the new invoice data.

Notification about and fetching of credit memo information

Another core use case is based on the usage of the enforePOS devices as a cash registers. Voids or sales returns performed via the enforePOS devices result in credit memo data being generated in the enfore platform (cf. MetaCompany "Ledger" module). The credit memo data generated in the enfore platform must then be copied into the external ERP system.

For that, the ERP-API will provide the functionality to subscribe to an "credit memo data available" event as well as a way to fetch the new credit memo data.

Domain model

The domain model of the ERP-API consists of the core object types Product, Invoice and CreditMemo. Other objects such as Customer and Staff are part of different APIs. In essence, Staff sells Products to Customers and each sale is recorded as an Invoice. Voids or sales returns are recorded as CreditMemo.

Product

A Product represents an item that is being sold by the business.

Each product has a name and various identifiers. The id is the technical identifier by which the enfore platform addresses the product. The external_id is an identifier that can be set via the ERP-API and that allows integrators to address the product directly without the need for a lookup. The article_id is the identifier by which the business communicates with the customer (aside from he product's name), it is shown on invoice documents, for example. Further identifiers can be stored as part of the product_identifiers structure, for example EAN and GTIN numbers.

Each product must have a management_unit. This unit, combined with the numeric value one, defines the minimum quantity of the product that can be addressed. For example, a product using MASS_KILOGRAMS as management unit can only be addressed in integer multiples of 1kg. It would not be possible to have a sale, purchase or stock change of 1.5kg or 500g of the product.

As products are to be sold, they also need a sales_quantity and a sales_price. The sales_quantity specifies the default quantity for a sale and the sales_price specifies the price for that default quantity of the product. For example, given product with the sales quantity of 5kg and the sales price of 10€, a customer purchasing 20kg of said product would need to pay 40€. The flag sales_price_is_gross indicates whether the sales_price is a net amount (when sales_price_is_gross == false) or a gross amount (when sales_price_is_gross == true).

For computing VAT/sales tax, each product must define its tax_category. Additionally it may define a reason for it to be exempt from taxation via its tax_exemption_reason field.

Product relationships

NOTE: The ERP-API currently does not provide a way to declare or query product relationships. This functionality will be added in the future. But as the enforePOS client allows creation of such relationships, the ERP-API must be able to represent the resulting invoice item dependencies and for understandng those, the following documentation was added.

The enfore platform allows modelling of relationships between products. Different types of relationships exist, and they influence the behavior of the platform in different ways.

Related products

A very simple form of product relationship is the "related product". When a product B is configured as a "related product" to product A, the register UI will suggest a sale of product B whenever product A is placed into the basket.

The "related product" relationship allows specifying a quantity and price for the linked product that differ from its regular sales quantity and price. This enables easy cross-selling products at a discount.

Options and option groups

When a product is configurable for a specific sale, it is often convenient to not model all possible configurations as separate products but to model the "core product" and its "options". When options are mutually exclusive, they can be wrapped in an "option group". Selection from a group may then also be set to mandatory.

For example, a product "Flat White" represents a coffee that does contain milk but may provide the choice between regular and soy milk. This would ideally be modeled as three products "Flat White", "Regular Milk" and "Say Milk" with the "Flat White" product having an option group "Milk" that referenced the other two products as "options" and whose "selection is mandatory" flag would be set.

If the "Flat White" additionally allowed the choice of having chocolate sprinkles on top, a fourth product "Chocolate Sprinkles" could be defined and the "Flat White" would reference that as an "option".

An "option" always references a product and may have a quantity/price that overrride that products regular sales quantity/price. It also has a flag controlling whether the option can be selected multiple times.

An "option group" bundles multiple "options" under a user-defined label. It has flags that control whether selection from the group is mandatory or optional and whether multiple or only one option from the group can be choosen.

Deposits

Deposit relationships represent "bottle deposit" that the customer has to pay when purchasing an item. For example, a when selling a drink in a disposable bottle in Germany, the merchant is required to collect a deposit of 0.25€. The customer can get the deposit refunded when she returns the empty bottle to the merchant later.

This usually is modeled by defining two products. One for the drink and another one for the deposit. The drink product would then reference the deposit product via a "deposit" relationship.

Custom workflows

The enfore platform provides extension points where the regular behavior of the platform can be extended and/or overridden by custom logic. This feature is known as "custom workflows". The API allows setting the start URLs for the product-related custom workflows via the field custom_workflow_config.

For more information regading custom workflows, please see CUWO architecture and interfaces (internal link).

Invoice

An Invoice represents the financial result of a sale.

It consists of various context information such as the store where the sale took place (via store_id), what register was used (via register_id) and which staff member handled the sale (via operator_id). The date and time of the sale is recorded as transaction_date_and_time.

Each invoice has a sequence of items that hold information about the products that were sold. Each item specifies the product that was sold, the sold quantity, the net/gross amounts, and any applied taxes and item-level discounts.

An invoice also has sequences of discounts and payments. The former hold information about basket-level discounts and the latter hold information about the payments made by the customer.

Edge cases

While ERP-API is focussed on the "retail" vertical and tries to provide a domain-specific view on the business data, the enfore platform provides some advanced features that cannot easily be mapped to this domain-specific view.

Invoices resulting from split/merged orders

The enfore platform uses "order" objects to represent sales. In the retail vertical, an "order" can be seen as to be equivalent to the list of items shown on the cash register. An order itself does not represent a sale yet, as it can be still be changed and/or aborted. Usually, once the merchant and customer agree on the sale, the order is converted into an invoice.

Nevertheless, the enfore platform allows invoices to be created for only part of an order, for a combination of multiple orders, or for a combination of both. For example, in the "gastro" vertical, it is common to use "one order per table" as this allows dishes to be served together and easy hand-over between waiters on shift changes. When creating invoices, it then often happens that each person/couple at the table requests a separate invoice. Or that a larger group of people is split accross multiple tables but then requsts a single, combined invoice.

When an invoice does not represent a single, complete order anymore, some additional definitions are needed to reason about the fields in the ERP-API:

• The values for store_id, register_id, transaction_date_and_time, and operator_id, are where, when and by whom the combined/split invoice was created.
• The values for transaction_start and transaction_end are the earliest start/lastest end of all orders that have at least one item included in the invoice.
• When combining/splitting orders, discounts may be recomputed. Whether discounts are computed on the invoice- or order-level depends on the sale process. For example, "gastro" orders may be merged and then discounts are recomputed based on the combined invoice. For "online" orders, there may be partial invoices caused by partial shipments but discounts are still computed based on the original order.

Late payments

The ERP-API allows clients to be notified about new invoices and when fetched, those invoices include information about the payment(s) made by the customer.

The enfore platform provides a feature called "pay later" where an invoice is created and booked but payment is deferred to a later point in time. In such cases, the ERP-API will send a notification about the new invoice, but when the invoice is fetched before the payment took place, the returned Invoice object will not include the payment information.

The ERP-API currently does not provide "payments" as a separate object type or notifications about "payments".

InvoiceItem

An InvoiceItem represents a single position in an invoice.

It references a product via its product_id and product_external_id. The quantity of product that was sold is recorded in the item's quantity field. The total amount of the item is available via gross_amount and net_amount.

Information about item-level discounts is available as discounts sequence and the undiscounted amounts of the item are stored in undiscounted_gross_amount and undiscounted_net_amount.

Information about taxes is available as taxes sequence. A sequence is used here as multiple taxes might be applied to a single item, for example US sales tax usually consists of a general state sales tax and local or city sales taxes. In those cases, a single InvoiceItem may have multiple TaxInformation elements.

Dependencies between items

An invoice item can depend on other invoice items. Dependencies on invoice items are caused by relations between products. For example, when a product A that has a related deposit product B, the invoice item for A will also have a dependant invoice item for B.

See the section about product relationships for more information.

CreditMemo

A CreditMemo represents the financial result of a sales void or sales return.

It is structurally almost equal to an Invoice with the exception that there are no discounts.

CreditMemoItem

A CreditMemoItem represents a single position in a credit memo.

It is structurally almost equal to an InvoiceItem with the exception that there are no discounts or item dependencies.

Customer

See the contacts API.

Staff

See the staff members & access rights API.

Product features

In the enfore platform, products have various properties that are explicitly modeled in the Product data structure and its subresources. For example, the product's name, management unit, sales price/quantity, etc.

Naturally, not all properties of every product in the world can be modeled. Trying to do this would work against the goal of the "MetaCompany" model being suitable to all kinds of businesses. Therefore, the enfore platform has a generic way to express custom product properties by the way of "product features".

In short, "product features" allow custom properties to be declared by the merchant for any of his products. Those custom properties can be organized in various ways and can be configured to be shown in different UI contexts as needed by the merchant.

The domain model for "product features" mainly consists of the data types FeatureTemplate, ProductFeature and various types of FeatureValue/FeatureValues.

A FeatureTemplate exists independent of any Product and describes a custom property (without actually assigning it to any Product yet). The template has a name, type, value type, a list of possible values and various additional information. For example, a tailer shop might define a feature template named "Color" with the type COLOR and the possible values of "Red", "Green", and "Black". And it might also define a feature template named "Arm length" with the type SIZE and the possible "length" values of 30cm and 26cm.

Note that the "possible values" declared as part of a FeatureTemplate consist of both the definition of the value type and the definition of the actual values. The type is mandatory and static but the actual values may change over time.

In addition to the type, feature templates can also be organized by category and group. Categories are predefined by enfore (currently only SPECIFICATIONS and INGREDIENTS exist) whereas groups can be defined by the merchant (although enfore does provide a couple of pre-defined groups, e.g., "allergens" or "dietary information").

Once a feature template has been defined, a Product can declare a ProductFeature to define that "this product has that feature/that custom property". The ProductFeature references a FeatureTemplate and (optionally) specifies a value (from the ones allowed by the template). E.g., the "Green Shirt" product may have the features "Color" with value "Green" and "Arm length" with value 26cm.

The value in the ProductFeature is optional so we can support some advanced use cases:

• Products with variants (where the variants are implicitly defined by feature value combinations)
  E.g., Product "T-Shirt" with variant-defining features "Color" (values red, green, blue) and "Size" (values S, M, L) would have the 6 variants red/S, red/M, red/L, green/S, green/M, green/L, blue/S, blue/M, and blue/L
• Products with feature values that differ by Lot
  E.g., Product "Red Roses" with feature "Stem length" defined "per Lot"

Feature types & values

Each product feature must be assigned a type and a value_type. Most also have a list of possible values (in the template) and a value (in the product/lot).

Since product features are effectively object properties, they always have some kind of value, at least from an abstract interpretation.

Take for example a product like a "Shopping bag". It could have the following properties:

• Material = Cotton
• Base color = Grey
• Highlight color = Red
• Weight = 350g
• Volume capacity = 10l
• Weight capacity = 15kg
• Size = M
• Food safe = yes
• Washable = yes

The type of a feature defines the semantic type of the feature's value. The following feature types exist:

The value_type of a feature defines the technical type of the feature's value. The following feature value types exist:

Note that the feature type limits the allowed feature value types:

Feature categories & groups

To organize features, merchants can use feature categories and feature groups. Both are use to determine which features are displayed where in the UI. For example, the product info view will use a tab for each category and then group the features of each tab by feature group.

Feature display configuration

Giving merchants the option to declare custom properties for their products is only useful if those custom properties are also visible in the client UI and/or on business documents.

For this, each FeatureTemplate and ProductFeature provide a "display configuration".

A FeatureDisplayConfiguration allows the merchant to choose an icon (from the list of built-in icons) and a color (from the list of defined "highlight colors") and specfiy a list of "UI contexts" in which the feature shall be shown.

The configuration on the FeatureTemplate serves as a blueprint for the configuration on the ProductFeature. It is copied from the FeatureTemplate on creation of the ProductFeature but is then "detached" from it (i.e., the configuration on the ProductFeature doesn't update when the configuration on the related FeatureTemplate is modified). For the actual display, only the configuration on the ProductFeature is taken into account.

Icons

The enfore platform defines a right set of icon to choose from.

Since there are too many icons to list them all here (and the icon set gets extended all the time), please refer to the source repo.

Colors

The enfore platform currently defines six highlight colors to choose from:

• GLUE
• GOLDEN
• PURPLE
• TEAL
• YELLOW

When no specific color is chosen by the merchant, a generic fallback color is automatically used.

Display contexts

The enfore platform defines the following display contexts for product features:

Browse Nodes

The enfore platform provides various places where users and/or customers can view the organizations products. Aside from search, and product lists, the primary way to navigate products is via "browse nodes".

Browse nodes are defined by the organization (vie API or client UI) and form an acyclic graph that can be navigated. Each node in the graph is called a browse node and any single product might be associated with any number of browse nodes.

For example, an electronics store selling gaming consoles might create a browse node graph like this:

A single product can be assigned to any number of browse nodes. For example, the Xbox version of the video game "F1 2020" may be assiged to XBox > Games > Sports and XBox > Games > Racing.

Note that it is possible to assign products to non-leaf browse nodes. For example, a game that doesn't fit into one of Action, Racing, Sports or Family could be directly assigned to Games

Order of child nodes for a browse node

Browse nodes form a directed acyclic graph via their parent->child relationships. For purposes of displaying child nodes of a specific parent to the user, an order over the children of a parent is necessary.

That order can be explicitly contolled via the /org/{org-id}/browse-nodes/{browse-node-id}/children endpoint.

When modifying the list of children indirectly (via PUT on a specific node with a different set of parents or via POST of a new node), new children are always appended to the existing list of children.

Product variants

Products often come in different variants. For example, a specific harddisc model exists with different storage capacities. Or a type of trousers comes in different sizes and colors.

To translate this into the enfore platform, each variant is expressed as a product ((Inventory)Product, BTOProduct, StaticSetProduct) and all those products are linked to a ProductVariantGroup.

For example, the "980 PRO NVMe M.2 SSD" product family could be expressed as

While the above example shows all variants having the same set of features, this isn't a requirements. It is possible to have variants with different sets of features or even without any features at all.

Note that is is also possible to have variant groups consist of products of different types (Inventory, BTO, Static Set)

Defining product variant groups

Before a product can be assigned to a product variant group, the group first has to be created via POST against /org/{org-id}/product-variant-group. Trying to assign a product to a non-existent variant group will fail with a 422 error.

Operations batches

The ERP-API provides "operations batches" that allow clients to upload a whole set of operations of the same type to be executed as a batch. This allows for a controlled execution of thousands of updates without needing an independent HTTP call for each operation.

The basic concept is that clients create a ZIP file containing all the single operations that they want to have executed as part of the batch, then request an "S3 upload URL" via GET /org/{org-id}/operations-batches/upload-url, then upload the ZIP file to that URL, and then trigger creation and execution of the batch via a call to POST /org/{org-id}/operations-batches/XXX (where XXX depends on the type of batch).

Batch payload ZIP file

The single operations included in an operations batch are to be provided as a ZIP file. Within the ZIP file, a single JSON file is expected for each single operation. The name of the file must be the ID of the operation followed by .json.

Operations are executed in the order of their IDs, sorted as ASCII ascending.

For example, an '"valid from"-price update' batch that aims to change the future prices for a single product on three different sales channel as well as the base price of the product would need to consist of four operations:

// Product base prices
{
    "@type": "ProductValidFromPriceUpdate",
    "operation_id": "no_channel",
    "product": {…},
    "price_list": […]

}

// Product prices for sales channel 1
{
    "@type": "ProductSalesChannelValidFromPriceUpdate",
    "operation_id": "c1",
    "product": {…},
    "sales_channel": {
        "id": "61bc6aa66e5ecde3f5caa2cd",
        "type": "POS_SALES_CHANNEL"
    },
    "price_list": […]
}

// Product prices for sales channel 2
{
    "@type": "ProductSalesChannelValidFromPriceUpdate",
    "operation_id": "c2",
    "product": {…},
    "sales_channel": {
        "id": "61bc6aab98ad9ead7d332972",
        "type": "POS_SALES_CHANNEL"
    },
    "price_list": […]
}

// Product prices for sales channel 3
{
    "@type": "ProductSalesChannelValidFromPriceUpdate",
    "operation_id": "c3",
    "product": {…},
    "sales_channel": {
        "id": "61bc6aaf317c902434238bbd",
        "type": "POS_SALES_CHANNEL"
    },
    "price_list": […]
}

Therefore, the ZIP file is expected to contain the four files:

• no_channel.json
• c1.json
• c2.json
• c3.json

The operations would then be executed in the order c1, c2, c3, no_channel.

The ZIP file must be a basic ZIP file that does not use any advanced features like encryption, volume spanning/segmentation, digital signatures or compression algorithms other than DEFLATE. At the minimum, the file must be fully compatible with the Java ZipInputStream implementation.

Types of operations batches

Each type of batch allows only a limited set of operation types as its payload. This is done so the enfore platform can optimize execution of the operations by, for example, using different scheduling and/or caching options for each type of batch. Additionally, having only operations of related type on one batch helps users when viewing the list of active/complete batches.

"Valid from"-price updates

A batch of type "Valid from"-price updates supports two types of operations:

• ProductValidFromPriceUpdate - Update (or remove) the list of "valid from"-base prices for a product
• ProductSalesChannelValidFromPriceUpdate - Update (or remove) the list of channel-specific "valid from"-prices for a product

ProductValidFromPriceUpdate:

    ProductValidFromPriceUpdate:
      type: object
      properties:
        "@type":
          type: string
          enum: ["ProductValidFromPriceUpdate"]
        operation_id:
          type: string
          minLength: 1
          maxLength: 256
        product:
          $ref: 'product_shared.yaml#/components/schemas/ProductReference'
        price_list:
          $ref: 'product_valid_from_prices.yaml#/components/schemas/ValidFromPricesList'
      required:
        - "@type"
        - operation_id
        - product

ProductSalesChannelValidFromPriceUpdate:

    ProductSalesChannelValidFromPriceUpdate:
      type: object
      properties:
        "@type":
          type: string
          enum: ["ProductSalesChannelValidFromPriceUpdate"]
        operation_id:
          type: string
          minLength: 1
          maxLength: 256
        product:
          $ref: 'product_shared.yaml#/components/schemas/ProductReference'
        sales_channel:
          $ref: 'product_shared.yaml#/components/schemas/SalesChannelReference'
        price_list:
          $ref: 'product_valid_from_prices.yaml#/components/schemas/ValidFromPricesList'
      required:
        - "@type"
        - operation_id
        - product
        - sales_channel

Appendix A - Key data

This section covers key data elements used by enfore. Most of those are reused for multiple data structures.

Country

We use ISO 3166 Alpha-2 codes for denoting countries. We support all currently defined countries.

Currency

We use ISO 4217 codes for denoting currencies. We currently can store the following currencies:

TaxCategory

We assign a single "tax category" to each sales item to control how sales of that item are taxed. The tax categories are locale independent and do not represent an actual tax rate directly. Rather, this is handled by "tax rules" that are configured in the platform. A "tax rule" defines conditions and references an actual "tax". The "tax" objects are the actual locale-specific taxes with their rate.

The platform currently defines the following tax categories:

TaxExemptionReason

For product where no VAT/sales tax is to be applied on a sale, a tax exemption reason must be given.

UnitOfMeasure

For denoting the unit of measure for a Quantity value, we use a fixed set units split by type (e.g., length, mass, volume). We currently support the following units of measure:

Digital information

Energy

Length

Mass

Quantity

Time

Volume

Appendix B - Common value object types

There are some common types of value objects that are repeatedly used within the actual business model objects.

Address

An Address represents a street address/postal address.

Money

A Money represents a monetary value (i.e., a currency and an amount), for example "120 EUR" or "2,500.75 USD".

Quantity

A Quantity represents a quantity value (i.e., a unit and an amount), for example "3 pcs" or "2.5 kg".

Introduction (Spec)

The purpose of the External ID Service is to support integrators. It provides means to store mappings between their own external ID and Enfores internal ID. At its current state, it is basically a key/value store.

Mapping

• need to be bijective, that means key/value must be unique in each direction.
• are scoped to:
  • organization
  • namespace
  • entity-class

A namespace must be created once before it's usable. Valid entity-classes are exposed by the external ID service itself.

Entity-classes are e.g.:

• products
• feature-templates
• feature-groups
• invoices
• sales-categories
• lots
• sales-orders
• staff-members
• bank-accounts

Introduction (Spec)

This documentation describes the high-level architecture of the enfore Inventory-API.

The enfore Inventory-API is provided by the enfore platform to be convenient to use for inventory-related use cases in the "Retail" vertical, for example when integrating with an external system such as SAP or Dynamics.

The API consists of multiple modules that allow

• notification about, querying and creation of stock count changes (e.g., items removed from stock due to a sale)
• notification about, querying and creation/update of inventory shipments (e.g., moving items from storage A to storage B)
• notification about, querying and creation/update of goods-in/out (e.g., receiving items from external to storage/moving items from storage to external)

The exact set of modules and their capabilities will evolve over time, the initial API version will only support a very limited set of use cases.

Use cases

• Domain model
  • InventoryShipment
    • Inventory shipment lifecycle
  • GoodsOut
    • Goods out lifecycle
    • Goods out types
  • GoodsIn
    • Goods-in lifecycle
  • StockCountChange

Domain model

The domain model of the Inventory-API consists of the core object types InventoryShipment, GoodsIn, GoodsOut, and StockCountChange.

The inventory management model of the enfore platform is based on a three-level hierarchy:

• At the top level are high-level business operations such as a sale of products to some customer (represented by a SalesOrder) or the transfer of inventory stock from one location to another (represented by an InventoryShipment).
• The middle level are unidirectional inventory movements of one or multiple products (represented by GoodsIn and GoodsOut objects)
• At the lowest level are the actual changes to stock count (represented by StockCountChange objects).

Objects at the top and middle level usually have some lifecycle. This allows such objects to be created without immediately having an effect on stock counts (e.g., one can sell a product to a customer but until it has been shipped, it is still part of the stock count). Once created, such objects usually can be rejected, accepted, performed, canceled, and completed. With the exact meaning of those states depending on the type of object.

Objects at the bottom level are purely for bookkeeping. They usually do not have a life cycle but are simple records of what happened.

The distinction between top and middle level is that top-level objects are business operations whereas mid-level objects are a technical abstraction/part of a top-level business operation. For example, an InventoryShipment is a business operation in which some quantity of some products is to be transferred from one storage location to another. In the enfore platform, this results in two middle-level objects being created. A GoodsOut for removing the stock from the source location and a GoodsIn for adding the stock to the target location. This allows staff at both locations to know what is to happend and perform their task. Once staff at the source location has packed and sent out the shipment, they can mark the GoodsOut as shipped and the system reduce the stock count accordingly (and create StockCountChange records). But until staff at the target location marks the GoodsIn as "received", the target location's stock count isn't increased yet.

InventoryShipment

An inventory shipment represents the business operation of transferring some quantity of some products from one storage location to another.

The API provides InventoryShipmentDraft objects for construcing an inventory shipment. An inventory shipment draft does not have any business impact yet and can freely be changed (positions added/changed/removed, locations updated, etc.) or deleted.

Once a draft is to become active, an InventoryShipment object must be created. Once created, an inventory shipment must traverse its life-cycle and cannot be deleted (but can be canceled). The creation of an inventory shipment also automatically creates a GoodsOut for the source location and a GoodsIn for the target location.

Inventory shipment lifecycle

The lifecycle of an inventory shipment consists of the initial state NEW, the two final states COMPLETED and CANCELED, and the intermediate state IN_PROCESS:

The meaning of the states is as follows:

GoodsOut

A GoodsOut represents the removal (usually via shipment) of some quantity of some products from a storage location.

Most GoodsOut objects belong to some high-level business operation such as an InventoryShipment or SalesOrder but the platform also allows for "unspecified/external" GoodsOut operations. Those are GoodsOut that are not created by the enfore platform based on high-level business operations but via the client or API. This is used for cases where the high-level operation isn't known (yet). For example for inventory shipments where the source location isn't modeled in the enfore platform, e.g., some kind of central enterprise warehouse.

To create an "unspecified/external" GoodsOut via the API, one first has to create a GoodsOutDraft and then create a GoodsOut from it. Similar to the inventory transfer API, the API for GoodsOutDraft provides functionality to freely modify/delete it whereas for GoodsOut, the API enforces a strict lifecycle.

Goods out lifecycle

The lifecycle of a goods out consists of the initial state PENDING, the two final states COMPLETED and CANCELED, and some intermediate states:

The meaning of the states is as follows:

Goods out types

A goods out has a type that indicates how the goods are moved. The following types are used by the API:

GoodsIn

A GoodsIn represents the addition (usually via shipment) of some quantity of some products to a storage location.

Most GoodsIn objects are related to (originate from)some high-level business operation such as an InventoryShipment or GoodsProcurement but the platform also allows for "unspecified/independent" GoodsIn operations. Those are GoodsIn that are not created by the enfore platform based on high-level business operations but via the client or API. This is used for cases where the high-level operation isn't known (yet). For example when a shipment from a customer is received but the customer hasn't notified the merchant about his intent to return the product yet. Another example is an external system that dispatches goods from a central warehouse to an organizations branches and where the central warehouse isn't modeled in the enfore platform.

To create an "unspecified/independent" GoodsIn via the API, one first has to create a GoodsInDraft and then create a GoodsIn from it. Similar to the inventory transfer API, the API for GoodsInDraft provides functionality to freely modify/delete it whereas for GoodsIn, the API enforces a strict lifecycle.

Goods-in lifecycle

The lifecycle of a goods-in consists of the initial state PLANNED, the three final states COMPLETED, CANCELED, and REJECED, and the intermediate state IN_PROCESS:

The meaning of the states is as follows:

StockCountChange

The enfore platform tracks stock count on a "per location + product + condition"-basis. That is, for each triplet of location, product and condition a separate stock count exists. Whenever the one such count changes, a StockCountChange object is created to record that change.

A StockCountChange object is only created once the change actually happened.

• Stock-taking
  • Domain model
    • enforePOS1
    • enforePOS2
  • Data export
    • Triggering data export
    • Export data format
      • CSV format rules
        • General
        • Numbers
        • Timestamps
      • File contents
        • meta.json
        • counting_areas.csv
        • participants.csv
        • resources.csv
        • area_counts.csv
        • counting_data.csv
        • counted_unique_items.csv

Stock-taking

Stock-taking is the process of physical verification of the actual quantities and conditions of goods held in a storage location.

Domain model

The enfore platform has support for stock-taking in enforePOS1 and enforePOS2 with a substantially different set of features. Therefore, there are two different domain models, one for enforePOS1 stock-taking and one for enforePOS2 stock-taking.

enforePOS1

An enforePOS1 stock-taking is represented by a StockTaking structure with a minimal set of configuration options. In enforePOS1, stock-taking is always performed by entering counting data on a resource-by-resource basis. There is no support for concurrent counting using multiple participants nor for counting areas.

The general life-cycle of an enforePOS1 stock-taking is rather simple:

enforePOS2

TBD

Data export

This section describes how data for a stock-taking can be exported via the enfore API and the format of the exported data.

Triggering data export

A data export for a stock-taking can be triggered by a POST /org/{org-id}/stock-taking-exports with a StockTakingReference identifying the stock-taking whose data to export as payload. Note that triggering an export is only possible for stock-takings that have reached a terminal state (CANCELED, COMPLETED, or COMPLETED_RECONCILIATION).

The state machine for a data export is simple:

The status of a StockTakingDataExport can be determined by polling. Once the status reaches COMPLETED, a download URL for the export data can be acquired via GET /org/{org-id}/stock-taking-exports/{export-id}/download.

The "happy-path" sequence of exporting data for a stock-taking is:

Export data format

The result of a data export for a stock-taking is a ZIP file containing a JSON file with meta-data about the stock-taking as well as a number of CSV files containing the counting and context data of the stock-taking.

The general structure of the ZIP file is:

CSV format rules

General

All CSV files of the stock-taking export format adhere to the CSV format as defined by RFC4180 and use a header row. The header row will contain the names of the columns as defined in the DBML definition for the export.

Numbers

All numbers are exported using the format pattern ###0.###. Values for columns defined as type integer do not contain a decimal separator or fractional digits.

Timestamps

All timestamps are exported as ISO 8601 timestamps with complete date plus hours, minutes, and seconds (but no fractional seconds) and using UTC timezone. That is, the format should match YYYY-MM-DDThh:mm:ssZ, e.g., 2000-05-24T13:15:30Z.

File contents

meta.json

The file meta.json contains the JSON structure StockTaking that can be acquired via the regular GET call in the API when querying a stock-taking.

For enforePOS1 stock-takings, this is the same as the response from GET /org/{org-id}/stock-takings-enfore-pos-1/{stock-taking-id}.

counting_areas.csv

The file counting_areas.csv contains a list of all counting areas of the stock-taking.

For enforePOS1 stock-takings and area-less enforePOS2 stock-takings, this fill will be empty.

The DBML definition for the file is:

Table counting_areas {
    id varchar [primary key, note: 'Technical ID of the counting area']
    name varchar [not null, note: 'Name of the counting area']
    type area_type [not null, note: 'Type of the counting area']

    Note: 'List of the counting areas of the stock-taking'
}

Enum area_type {
    STORAGE_AREA
    TEMPORARY_AREA
}

participants.csv

The file participants.csv contains a list of all participants of the stock-taking.

For enforePOS1 stock-takings, there is no device information and usually only a single participant exists.

For enforePOS2 stock-takings, there will be device information for all participants that have actually counted something. Participants that do not have counted may or may not have device information.

The DBML definition for the file is:

Table participants {
    id varchar [primary key, note: 'ID of the participant']
    staff_member_id varchar [not null, note: 'ID of the IndividualContact of the participant']
    staff_member_name varchar [not null, note: 'Name of the participant']
    device_id varchar [note: 'ID of the Device object used by the participant']
    device_name varchar [note: 'Name of the Device object used by the participant']

    Note: 'List of the participants of the stock-taking'
}

The value of the staff_member_id field is the identifier of the staff member that is participant of the stock-takings. The identifier can be used to fetch the staff member via the "Staff & Access Rights"-API endpoint /org/{org-id}/staff-members/{staff-member-id}. The identifier can also be used to fetch the IndividualContact of the staff member via the Contacts-API endpoint /org/{org-id}/individual/{contact-id}.

The value of the device_id field is the identifier of the device used by the participant of the stock-taking. The identifier can be used to fetch the device via the "Organization Structure"-API endpoints /org/{org-id}/devices/{device-id} or /org/{org-id}/enforepos-devices/{enforepos-device-id}.

resources.csv

The file resources.csv contains a list of all counted resource/condition pairs and aggregated count results for each.

The DBML definition for the file is:

Table resources {
    id varchar
    condition varchar
    name varchar
    article_id varchar
    tracking_unit unit_of_measure [not null]
    counted_units integer
    first_counted_on timestamp
    first_counted_by varchar
    last_counted_on timestamp
    last_counted_by varchar

    indexes {
        (id, condition) [pk]
    }

    Note: 'Information about the resources counted as part of the stock-taking'
}
Ref: resources.first_counted_by > participants.id
Ref: resources.last_counted_by > participants.id

Enum unit_of_measure {
    ENERGY_JOULES
    ENERGY_GIGAJOULES
    ENERGY_MEGAJOULES
    ENERGY_KILOJOULES
    ENERGY_CENTIJOULES
    ENERGY_MILLIJOULES
    ENERGY_MICROJOULES
    ENERGY_CALORIES
    ENERGY_KILOCALORIES
    ENERGY_WATTHOURS
    ENERGY_GIGAWATTHOURS
    ENERGY_MEGAWATTHOURS
    ENERGY_KILOWATTHOURS
    ENERGY_CENTIWATTHOURS
    ENERGY_MILLIWATTHOURS
    ENERGY_MICROWATTHOURS
    LENGTH_KILOMETERS
    LENGTH_METERS
    LENGTH_DECIMETERS
    LENGTH_CENTIMETERS
    LENGTH_MILLIMETERS
    LENGTH_POINTS
    LENGTH_INCHES
    LENGTH_FEET
    LENGTH_YARDS
    MASS_TONS
    MASS_KILOGRAMS
    MASS_GRAMS
    MASS_MILLIGRAMS
    MASS_POUNDS
    QUANTITY_PIECES
    TIME_SECONDS
    TIME_MINUTES
    TIME_HOURS
    TIME_DAYS
    TIME_WEEKS
    DIGITALINFORMATION_BYTES
    DIGITALINFORMATION_KILOBYTES
    DIGITALINFORMATION_KIBIBYTES
    DIGITALINFORMATION_MEGABYTES
    DIGITALINFORMATION_MEBIBYTES
    DIGITALINFORMATION_GIGABYTES
    DIGITALINFORMATION_GIBIBYTES
    DIGITALINFORMATION_TERABYTES
    DIGITALINFORMATION_TEBIBYTES
    DIGITALINFORMATION_PETABYTES
    DIGITALINFORMATION_PEBIBYTES
    TIME_MONTHS
    TIME_YEARS
    VOLUME_CUBIC_MILLIMETERS
    VOLUME_CUBIC_CENTIMETERS
    VOLUME_CUBIC_DECIMETERS
    VOLUME_CUBIC_METERS
    VOLUME_MILLILITERS
    VOLUME_CENTILITERS
    VOLUME_DECILITERS
    VOLUME_LITERS
    VOLUME_HECTOLITERS
    VOLUME_FLUID_OUNCES
    VOLUME_PINTS
    VOLUME_QUARTS
    VOLUME_GALLONS
    VOLUME_BARRELS
}

Note that the file uses a composite primary key consisting of the resource and condition columns. That means, that there may be multiple records for the same resource, when the resource exists in multiple conditions.

The value of the id field is the identifier of the resource that has been counted as part of the stock-taking. If the resource is a product, the identifier can be used to fetch the product via the ERP-API endpoint /org/{org-id}/products/{product-id}.

The value of the condition field identifiers the condition of the counted resource. For enforePOS1 stock-takings, the value of the column is the name of the condition (one of NEW, REFURBISHED, USED_LIKE_NEW, USED_VERY_GOOD, USED_GOOD, USED_ACCEPTABLE, DAMAGED).

area_counts.csv

The file area_counts.csv contains a list of all area counts performed as part of the stock-taking.

This file will be empty for enforePOS1 stock-taking and area-less enforePOS2 stock-takings.

The DBML definition for the file is:

Table area_counts {
    id varchar [primary key]
    area varchar
    participant varchar

    Note: 'List of the are counts of the stock-taking'
}
Ref: area_counts.area > counting_areas.id
Ref: area_counts.participant > participants.id

counting_data.csv

The file counting_data.csv contains the low-level stock count data provided by the participants of the stock-taking.

For enforePOS1 stock-takings, low-level data is not stored, so the file essentially contains the same count data as resources.csv.

For enforePOS2 stock-takings, low-level data is stored and made available via this file in the export.

The DBML definition for the file is:

Table counting_data {
    id varchar [primary key]
    resource varchar [not null]
    condition varchar
    lot varchar
    counted_units integer [not null]
    counted_on timestamp [not null]
    counted_by varchar [not null]
    area_count varchar

    Note: 'List of counting data of the stock-taking'
}
Ref: counting_data.resource > resources.id
Ref: counting_data.counted_by > participants.id
Ref: counting_data.area_count > area_counts.id

The value of the resource field is the identifier of the resource that has been counted as part of the stock-taking. If the resource is a product, the identifier can be used to fetch the product via the ERP-API endpoint /org/{org-id}/products/{product-id}.

The value of the condition field identifiers the condition of the counted resource. For enforePOS1 stock-takings, the value of the column is the name of the condition (one of NEW, REFURBISHED, USED_LIKE_NEW, USED_VERY_GOOD, USED_GOOD, USED_ACCEPTABLE, DAMAGED).

The value of the lot field is the identifier of the lot that the counted units belong to. The identifier can be used to fetch the lot via the ERP-API endpoint /org/{org-id}/lots/{lot-id}.

counted_unique_items.csv

The file counted_unique_items.csv contains the list of all unique item units that have been counted as part of the stock-takings.

As enforePOS1 stock-takings do not support counting unique item units, this file will be empty in exports of enforePOS1 stock-takings.

The DBML definition for the file is:

Table counted_unique_items {
    id varchar [primary key]
    resource varchar [not null]
    lot varchar
    condition varchar
    counted_via varchar [not null]

    Note: 'List of unique items counted as part of the stock-taking'
}
Ref: counted_unique_items.resource > resources.id
Ref: counted_unique_items.counted_via > counting_data.id

• GoodsIn - Examples
  • Received values
    • Simple product
    • Product with condition and lot
    • Multiple records and under/overdelivery
    • Setting and clearing
    • Delta computation edge cases
      • Deltas against non-existing values
      • Deltas when changing the item's unit or expected number of units
  • Resolutions
    • Basic Collect
    • Discard before Collect
    • Collect, then adjust and Discard
  • Full use cases
    • Case 1 - overdelivery, discard, overdelivery, collect
    • Case 2 - overdelivery, collect, discard, overdelivery, collect
    • Case 3 - overdelivery, discard, revert discard, discard, underdelivery
    • Case 4 - regular delivery, collect, reset to planned, overdelivery, collect + discard

GoodsIn - Examples

Received values

Simple product

During review of the received goods, the user will set the received values. This will not only update the received_… fields but also add entries to the received_values_change_log.

The following JSON shows an example for a GoodsInItem for a basic product (no custom unit, lots, conditions, unique item identifiers) where the received values have been set exactly once:

{
  "id": "635f9c9f5fc3a61ae8df7861",
  "product_id": "635f9ca66496bb9e6bb94f44",
  "unit": {
    "value": 1,
    "unit": "QUANTITY_PIECES"
  },
  "expected_number_of_units": 10,
  "received_number_of_units": 10,
  "received_values_change_log": [
    {
      "id": "635f9ce3d3fef5e94a928e2f",
      "type": "SET_RECEIVED_NUMBER_OF_UNITS",
      "details": {
        "@type": "SetReceivedNumberOfUnitsChangeDetail",
        "new_received_number_of_units": 10,
        "unit": {
          "value": 1,
          "unit": "QUANTITY_PIECES"
        },
        "delta_to_previous_quantity": {
          "number_of_delta_units": 10,
          "delta_unit": {
            "value": 1,
            "unit": "QUANTITY_PIECES"
          }
        },
        "delta_to_expected_quantity": {
          "number_of_delta_units": 0,
          "delta_unit": {
            "value": 1,
            "unit": "QUANTITY_PIECES"
          }
        }
      },
      "timestamp": "2019-08-24T14:15:22Z"
    }
  ]
}

Product with condition and lot

If the product uses conditions or lots, the user must also confirm/set the received_condition_id and received_lot_id fields during review of the received goods. Setting those values will cause additional entries to show up in the received_values_change_log.

The following JSON shows an example for a GoodsInItem for a product using conditions and lots where the user first confirmed condition & lot and then the received quantity:

{
  "id": "635f9c9f5fc3a61ae8df7861",
  "product_id": "635f9ca66496bb9e6bb94f44",
  "unit": {
    "value": 1,
    "unit": "QUANTITY_PIECES"
  },
  "expected_number_of_units": 10,
  "received_number_of_units": 10,
  "received_values_change_log": [
    // Setting received condition
    {
      "id": "635f9e9a3012cc3fb567d0c0",
      "type": "SET_RECEIVED_CONDITION",
      "details": {
        "@type": "SetReceivedConditionChangeDetail",
        "new_received_condition_id": "635f9e6a6e681b0aa44de228"
      },
      "timestamp": "2019-08-24T14:12:32Z"
    },

    // Setting received lot
    {
      "id": "635f9ea157e6f172f9896b7d",
      "type": "SET_RECEIVED_LOT",
      "details": {
        "@type": "SetReceivedLotChangeDetail",
        "new_received_lot_id": "635f9e91054ea41382105f72"
      },
      "timestamp": "2019-08-24T14:13:56Z"
    },

    // Setting received quantity
    {
      "id": "635f9ea8976541f10f843631",
      "type": "SET_RECEIVED_NUMBER_OF_UNITS",
      "details": {
        "@type": "SetReceivedNumberOfUnitsChangeDetail",
        "new_received_number_of_units": 10,
        "unit": {
          "value": 1,
          "unit": "QUANTITY_PIECES"
        },
        "delta_to_previous_quantity": {
          "number_of_delta_units": 10,
          "delta_unit": {
            "value": 1,
            "unit": "QUANTITY_PIECES"
          }
        },
        "delta_to_expected_quantity": {
          "number_of_delta_units": 0,
          "delta_unit": {
            "value": 1,
            "unit": "QUANTITY_PIECES"
          }
        }
      },
      "timestamp": "2019-08-24T14:15:22Z"
    }
  ]
}

Multiple records and under/overdelivery

Sometimes the user needs to modify received values after having set the initially. For example, the user might record a received quantity less than the expected one but later discover more units of the product in the received goods.

In such cases, multiple SET_RECEIVED_… entries for the same information (number of units, condition, lot) will be present in the log.

The following JSON shows an example for a GoodsInItem where the user first recorded an underdelivery of two units but later adjusted the recieved number of units to an overdelivery of one unit:

{
  "id": "635f9c9f5fc3a61ae8df7861",
  "product_id": "635f9ca66496bb9e6bb94f44",
  "unit": {
    "value": 1,
    "unit": "QUANTITY_PIECES"
  },
  "expected_number_of_units": 10,
  "received_number_of_units": 11,
  "received_values_change_log": [
    // Initial "set received number of units" - underdelivery
    {
      "id": "635f9ce3d3fef5e94a928e2e",
      "type": "SET_RECEIVED_NUMBER_OF_UNITS",
      "details": {
        "@type": "SetReceivedNumberOfUnitsChangeDetail",
        "new_received_number_of_units": 8,
        "unit": {
          "value": 1,
          "unit": "QUANTITY_PIECES"
        },
        "delta_to_previous_quantity": {
          "number_of_delta_units": 8,
          "delta_unit": {
            "value": 1,
            "unit": "QUANTITY_PIECES"
          }
        },
        "delta_to_expected_quantity": {
          "number_of_delta_units": -2,
          "delta_unit": {
            "value": 1,
            "unit": "QUANTITY_PIECES"
          }
        }
      },
      "timestamp": "2019-08-24T14:15:22Z"
    },

    // Second "set received number of units" - overdelivery
    {
      "id": "635fa1e7836870497c5f12bd",
      "type": "SET_RECEIVED_NUMBER_OF_UNITS",
      "details": {
        "@type": "SetReceivedNumberOfUnitsChangeDetail",
        "new_received_number_of_units": 11,
        "unit": {
          "value": 1,
          "unit": "QUANTITY_PIECES"
        },
        "delta_to_previous_quantity": {
          "number_of_delta_units": 3,
          "delta_unit": {
            "value": 1,
            "unit": "QUANTITY_PIECES"
          }
        },
        "delta_to_expected_quantity": {
          "number_of_delta_units": 1,
          "delta_unit": {
            "value": 1,
            "unit": "QUANTITY_PIECES"
          }
        }
      },
      "timestamp": "2019-08-24T14:15:22Z"
    }
  ]
}

Setting and clearing

In case the received values have been set by mistake, they must be cleared. For condition and lot, this is done by simply recording a SET_RECEIVED_CONDITION/SET_RECEIVED_LOT entry with no condition/lot identifier. For the received number of units though, a dedicated CLEAR_RECEIVED_NUMBER_OF_UNITS entry type exists.

The reason for the dedicated entry type is that there is a difference in having received_number_of_units == 0 and received_number_of_units == null. The former indicates that the review of the GoodsInItem has been performed and that no units have been delivered for the item. The latter indicates that the review for the item has not yet been done.

The following JSON shows an example for a GoodsInItem where the user first sets the received values (condition, lot, number of units) and then later clears them again:

{
  "id": "635f9c9f5fc3a61ae8df7861",
  "product_id": "635f9ca66496bb9e6bb94f44",
  "unit": {
    "value": 1,
    "unit": "QUANTITY_PIECES"
  },
  "expected_number_of_units": 10,
  "received_number_of_units": null,
  "received_values_change_log": [
    // Setting received condition
    {
      "id": "635f9e9a3012cc3fb567d0c0",
      "type": "SET_RECEIVED_CONDITION",
      "details": {
        "@type": "SetReceivedConditionChangeDetail",
        "new_received_condition_id": "635f9e6a6e681b0aa44de228"
      },
      "timestamp": "2019-08-24T14:12:32Z"
    },

    // Setting received lot
    {
      "id": "635f9ea157e6f172f9896b7d",
      "type": "SET_RECEIVED_LOT",
      "details": {
        "@type": "SetReceivedLotChangeDetail",
        "new_received_lot_id": "635f9e91054ea41382105f72"
      },
      "timestamp": "2019-08-24T14:13:56Z"
    },

    // Setting received quantity
    {
      "id": "635f9ea8976541f10f843631",
      "type": "SET_RECEIVED_NUMBER_OF_UNITS",
      "details": {
        "@type": "SetReceivedNumberOfUnitsChangeDetail",
        "new_received_number_of_units": 10,
        "unit": {
          "value": 1,
          "unit": "QUANTITY_PIECES"
        },
        "delta_to_previous_quantity": {
          "number_of_delta_units": 10,
          "delta_unit": {
            "value": 1,
            "unit": "QUANTITY_PIECES"
          }
        },
        "delta_to_expected_quantity": {
          "number_of_delta_units": 0,
          "delta_unit": {
            "value": 1,
            "unit": "QUANTITY_PIECES"
          }
        }
      },
      "timestamp": "2019-08-24T14:15:22Z"
    },

    // Clearing received condition
    {
      "id": "635fa5843b20830e34b025b5",
      "type": "SET_RECEIVED_CONDITION",
      "details": {
        "@type": "SetReceivedConditionChangeDetail",
        "new_received_condition_id": null
      },
      "timestamp": "2019-08-24T15:20:33Z"
    },

    // Clearing received lot
    {
      "id": "635fa58cf1c5f1e6d254d254",
      "type": "SET_RECEIVED_LOT",
      "details": {
        "@type": "SetReceivedLotChangeDetail",
        "new_received_lot_id": null
      },
      "timestamp": "2019-08-24T15:20:33Z"
    },

    // Clearing received quantity
    {
      "id": "635fa59101e4eba19042d2c3",
      "type": "CLEAR_RECEIVED_NUMBER_OF_UNITS",
      "details": {
        "@type": "ClearReceivedNumberOfUnitsChangeDetail",
        "delta_to_previous_quantity": {
          "number_of_delta_units": -10,
          "delta_unit": {
            "value": 1,
            "unit": "QUANTITY_PIECES"
          }
        },
        "delta_to_expected_quantity": {
          "number_of_delta_units": -10,
          "delta_unit": {
            "value": 1,
            "unit": "QUANTITY_PIECES"
          }
        }
      },
      "timestamp": "2019-08-24T15:20:33Z"
    }
  ]
}

Delta computation edge cases

Note that there are a number of edge cases in the context of the delta computations. Notably computing deltas against non-existing values and computing deltas for goods-in items whose unit or expected number of units are changed.

Deltas against non-existing values

Deltas against non-existing values are needed for four cases:

• for goods-in items that do not have an expected_number_of_units set
• for all "received values change log"-entry with a ClearReceivedNumberOfUnitsChangeDetail
• for all "received values change log"-entry with a SetReceivedNumberOfUnitsChangeDetail that
  • are the first such entry in their change log
  • are the first such entry following an entry with a ClearReceivedNumberOfUnitsChangeDetail

Often, only a single value is missing. For example for the "delta to previous quantity" for the first SetReceivedNumberOfUnitsChangeDetail entry in the log. But there are cases where both values are missing. For example for the "delta to expected quantity" for a ClearReceivedNumberOfUnitsChangeDetail entry.

The missing values for such delta computations are substituted by generating a quantity with the numeric value of zero and the unit/custom unit taken from the other value (if it exists) or the goods-in item (for deltas where both values are missing).

For example, conider the following goods-in item:

D1P (marked in blue) is a "delta to previous quantity" where there is no "old received quantity" as the delta belongs to the first SetReceivedNumberOfUnitsChangeDetail in the log. The value 0x 1pc is substituted by taking the 1pc unit from the "new received quantity" (from the log entry the delta belongs to) and using zero as number of units.

D2P (marked in khaki/yellow) is a "delta to previous quantity" where there is no "new received quantity" as it belongs to a ClearReceivedNumberOfUnitsChangeDetail entry. The value 0x 1pc is substituted by taking the 1pc unit from the "previous received quantity" (from the preceeding log entry) and using zero as number of units.

D3P (marked in green) is a "delta to previous quantity" where there is no "old received quantity" as the delta belongs to the first SetReceivedNumberOfUnitsChangeDetail log entry after a ClearReceivedNumberOfUnitsChangeDetail entry. The value 0x 1pc is substituted by taking the 1pc unit from the "new received quantity" (from the log entry the delta belongs to) and using zero as number of units.

D1E and D3E (marked in tan/brown) are "deltas to expected quantity" where there is no "expected quantity" as the goods-in item does not have an expected number of units. The value 0x 1pc is substituted by taking the 1pcs unit from the "current received quantity" (from the log entries the deltas belong to) and using zero as number of units.

D2E (marked in gold) is a "delta to expected quantity" where both the "expected quantity" and the "current received quantity" are missing. The value 0x 1pc is substituted for both by taking the 1pcs unit form the goods-in item and using zero as number of units.

Deltas when changing the item's unit or expected number of units

Deltas for goods-in items whose unit or expected number of units is changed require special attention as they a) are often deltas between two values that use different units and b) are adjusted based on the changed unit.

Deltas between values using different units (e.g., a delta between 2kg (received qty) and 5000g (expected qty)) are computed by first converting both values into the product's "tracking unit" (e.g., 2kg to 5000g = 2000000mg to 5000000mg = -3000000mg, assuming mg as tracking unit).

As deltas

For example consider the following goods-in item and assume the product uses mg as tracking unit:

Note how a change in the item's expected number of units causes the "deltas to expected" to update:

A change to the goods-in item's unit causes most deltas to be adjusted to the changed unit too:

Note how the "deltas to the expected quantity" switched to the resource's tracking unit in case the "current received quantity" exists and uses a different unit (D1E and D3E) or to the item's unit in case no "curret received quantity" exists (D2E).

New entries in the log file will use the item's new unit, so their "delta to expected" will use that one too. The "delta to previous" will usually fall back to the tracking unit as the "old received quantity" uses the old unit:

Resolutions

Basic Collect

The most commonly used type of resolution is Collect. A Collect indicates that the delivered goods have been taken over moved into the recipients storage system.

The following JSON shows an example for a GoodsInItem where the full received quantity has been collected:

{
  "id": "635f9c9f5fc3a61ae8df7861",
  "product_id": "635f9ca66496bb9e6bb94f44",
  "unit": {
    "value": 1,
    "unit": "QUANTITY_PIECES"
  },
  "expected_number_of_units": 10,
  "received_number_of_units": 10,
  "resolved_number_of_units": 10,
  "resolutions": [
    {
      "id": "635fab5a1247c8cd74c0c48a",
      "affected_stock": {
        "number_of_units": 10,
        "unit": {
          "value": 1,
          "unit": "QUANTITY_PIECES"
        }
      },
      "details": {
        "@type": "GoodsInItemCollectResolutionDetails"
      },
      "status": "BOOKED",
      "status_log": [
        {
          "status": "PLANNED",
          "timestamp": "2019-08-24T14:15:22Z"
        },
        {
          "status": "BOOKED",
          "timestamp": "2019-08-24T16:32:56Z"
        }
      ]
    }
  ]
}

Note that the example omits the received_values_change_log for brevity.

Discard before Collect

Another common case is that some of the delivery goods is damaged/broken and thus cannot be collected.

If this is detected before recording the Collect, simply recording a Discard resolution for the broken units and then a Collect for the remaining units is possible.

The following JSON shows an example for a GoodsInItem where the two units are resolved as Discard and then the remaining eight units are collected:

{
  "id": "635f9c9f5fc3a61ae8df7861",
  "product_id": "635f9ca66496bb9e6bb94f44",
  "unit": {
    "value": 1,
    "unit": "QUANTITY_PIECES"
  },
  "expected_number_of_units": 10,
  "received_number_of_units": 10,
  "resolved_number_of_units": 10,
  "resolutions": [
    {
      "id": "635fab5a1247c8cd74c0c48a",
      "affected_stock": {
        "number_of_units": 2,
        "unit": {
          "value": 1,
          "unit": "QUANTITY_PIECES"
        }
      },
      "reason": {
        "@type": "PlatformDefinedGoodsInExceptionalResolutionReason",
        "name": "STATE_OF_GOODS"
      },
      "details": {
        "@type": "GoodsInItemDiscardResolutionDetails"
      },
      "status": "BOOKED",
      "status_log": [
        {
          "status": "PLANNED",
          "timestamp": "2019-08-24T14:15:22Z"
        },
        {
          "status": "BOOKED",
          "timestamp": "2019-08-24T14:23:33Z"
        }
      ]
    },
    {
      "id": "635faddf6c08f1086698fdd0",
      "affected_stock": {
        "number_of_units": 8,
        "unit": {
          "value": 1,
          "unit": "QUANTITY_PIECES"
        }
      },
      "details": {
        "@type": "GoodsInItemCollectResolutionDetails"
      },
      "status": "BOOKED",
      "status_log": [
        {
          "status": "PLANNED",
          "timestamp": "2019-08-24T16:25:43Z"
        },
        {
          "status": "BOOKED",
          "timestamp": "2019-08-24T16:32:56Z"
        }
      ]
    }
  ]
}

Collect, then adjust and Discard

Sometimes, mistakes are made or stock that was seen as "good" and thus has been collected is later found to be "not good".

Any case that requires changing the outcome of an already booked resolution requires an "adjustment" of the resolution.

The following JSON shows an example for a GoodsInItem where all ten units were Collected but later two units were found to be defective/broken and needed to be Discarded:

{
  "id": "635f9c9f5fc3a61ae8df7861",
  "product_id": "635f9ca66496bb9e6bb94f44",
  "unit": {
    "value": 1,
    "unit": "QUANTITY_PIECES"
  },
  "expected_number_of_units": 10,
  "received_number_of_units": 10,
  "resolved_number_of_units": 10,
  "resolutions": [
    {
      "id": "635fb36b8db8aa3a2625aca1",
      "affected_stock": {
        "number_of_units": 10,
        "unit": {
          "value": 1,
          "unit": "QUANTITY_PIECES"
        }
      },
      "details": {
        "@type": "GoodsInItemCollectResolutionDetails"
      },
      "status": "BOOKED",
      "status_log": [
        {
          "status": "PLANNED",
          "timestamp": "2019-08-24T14:29:00Z"
        },
        {
          "status": "BOOKED",
          "timestamp": "2019-08-24T14:30:00Z"
        }
      ],
      "adjustments": [
        {
          "id": "635fec1267743cd6f905a40d",
          "type": "DECREASE",
          "affected_stock": {
            "number_of_units": 2,
            "unit": {
              "value": 1,
              "unit": "QUANTITY_PIECES"
            }
          },
          "due_to": {
            "item_id": "635f9c9f5fc3a61ae8df7861",
            "resolution_id": "635fb3772ab68c151f3ce1a1"
          },
          "status": "BOOKED",
          "status_log": [
            {
              "status": "PLANNED",
              "timestamp": "2019-08-24T15:00:00Z"
            },
            {
              "status": "BOOKED",
              "timestamp": "2019-08-24T15:00:10Z"
            }
          ]
        }
      ]
    },
    {
      "id": "635fb3772ab68c151f3ce1a1",
      "affected_stock": {
        "number_of_units": 2,
        "unit": {
          "value": 1,
          "unit": "QUANTITY_PIECES"
        }
      },
      "reason": {
        "@type": "PlatformDefinedGoodsInExceptionalResolutionReason",
        "name": "STATE_OF_GOODS"
      },
      "details": {
        "@type": "GoodsInItemDiscardResolutionDetails"
      },
      "status": "BOOKED",
      "status_log": [
        {
          "status": "PLANNED",
          "timestamp": "2019-08-24T15:00:00Z"
        },
        {
          "status": "BOOKED",
          "timestamp": "2019-08-24T15:00:10Z"
        }
      ]
    }
  ]
}

Full use cases

Case 1 - overdelivery, discard, overdelivery, collect

The following JSON payload shows a GoodsInItem with an expected quantity of 2 KOL (where one KOL consists of 6 pcs) after the following operations have been performed by the user:

1. Setting received quantity to 3 KOL
2. Booking a Discard of 2 KOL due to damaged goods
3. Booking another Discard of 1 KOL due to damaged goods
4. Updating the received quantity to 5 KOL
5. Booking a Collect of 2 KOL

{
  "id": "635f9c9f5fc3a61ae8df7861",
  "product_id": "635f9ca66496bb9e6bb94f44",
  "unit": {
    "value": 6,
    "unit": "QUANTITY_PIECES"
  },
  "custom_unit_id": "635fb71a67743cd6f905a124",
  "expected_number_of_units": 2,
  "received_number_of_units": 5,
  "resolved_number_of_units": 5,
  "received_values_change_log": [
    // 1 - Setting received quantity to `3 KOL`
    {
      "id": "635fb73267743cd6f905a131",
      "type": "SET_RECEIVED_NUMBER_OF_UNITS",
      "details": {
        "@type": "SetReceivedNumberOfUnitsChangeDetail",
        "new_received_number_of_units": 3,
        "unit": {
          "value": 6,
          "unit": "QUANTITY_PIECES"
        },
        "custom_unit_id": "635fb71a67743cd6f905a124",
        "delta_to_previous_quantity": {
          "number_of_delta_units": 3,
          "delta_unit": {
            "value": 6,
            "unit": "QUANTITY_PIECES"
          },
          "custom_unit_id": "635fb71a67743cd6f905a124"
        },
        "delta_to_expected_quantity": {
          "number_of_delta_units": 1,
          "delta_unit": {
            "value": 6,
            "unit": "QUANTITY_PIECES"
          },
          "custom_unit_id": "635fb71a67743cd6f905a124"
        }
      },
      "timestamp": "2019-08-24T14:10:00Z"
    },

    // 4 - Updating the received quantity to `5 KOL`
    {
      "id": "635fb73267743cd6f905a134",
      "type": "SET_RECEIVED_NUMBER_OF_UNITS",
      "details": {
        "@type": "SetReceivedNumberOfUnitsChangeDetail",
        "new_received_number_of_units": 5,
        "unit": {
          "value": 6,
          "unit": "QUANTITY_PIECES"
        },
        "custom_unit_id": "635fb71a67743cd6f905a124",
        "delta_to_previous_quantity": {
          "number_of_delta_units": 2,
          "delta_unit": {
            "value": 6,
            "unit": "QUANTITY_PIECES"
          },
          "custom_unit_id": "635fb71a67743cd6f905a124"
        },
        "delta_to_expected_quantity": {
          "number_of_delta_units": 3,
          "delta_unit": {
            "value": 6,
            "unit": "QUANTITY_PIECES"
          },
          "custom_unit_id": "635fb71a67743cd6f905a124"
        }
      },
      "timestamp": "2019-08-24T14:40:00Z"
    }
  ],
  "resolutions": [
    // 2 - Booking a `Discard` of `2 KOL` due to damaged goods
    {
      "id": "635fb73267743cd6f905a132",
      "affected_stock": {
        "number_of_units": 2,
        "unit": {
          "value": 6,
          "unit": "QUANTITY_PIECES"
        },
        "custom_unit_id": "635fb71a67743cd6f905a124"
      },
      "reason": {
        "@type": "PlatformDefinedGoodsInExceptionalResolutionReason",
        "name": "STATE_OF_GOODS"
      },
      "details": {
        "@type": "GoodsInItemDiscardResolutionDetails"
      },
      "status": "BOOKED",
      "status_log": [
        {
          "status": "PLANNED",
          "timestamp": "2019-08-24T14:20:00Z"
        },
        {
          "status": "BOOKED",
          "timestamp": "2019-08-24T14:20:00Z"
        }
      ]
    },

    // 3 - Booking another `Discard` of `1 KOL` due to damaged goods
    {
      "id": "635fb73267743cd6f905a133",
      "affected_stock": {
        "number_of_units": 1,
        "unit": {
          "value": 6,
          "unit": "QUANTITY_PIECES"
        },
        "custom_unit_id": "635fb71a67743cd6f905a124"
      },
      "reason": {
        "@type": "PlatformDefinedGoodsInExceptionalResolutionReason",
        "name": "STATE_OF_GOODS"
      },
      "details": {
        "@type": "GoodsInItemDiscardResolutionDetails"
      },
      "status": "BOOKED",
      "status_log": [
        {
          "status": "PLANNED",
          "timestamp": "2019-08-24T14:30:00Z"
        },
        {
          "status": "BOOKED",
          "timestamp": "2019-08-24T14:30:00Z"
        }
      ]
    },

    // 5 - Booking a `Collect` of `2 KOL`
    {
      "id": "635fb73267743cd6f905a135",
      "affected_stock": {
        "number_of_units": 2,
        "unit": {
          "value": 6,
          "unit": "QUANTITY_PIECES"
        },
        "custom_unit_id": "635fb71a67743cd6f905a124"
      },
      "details": {
        "@type": "GoodsInItemCollectResolutionDetails"
      },
      "status": "BOOKED",
      "status_log": [
        {
          "status": "PLANNED",
          "timestamp": "2019-08-24T14:50:00Z"
        },
        {
          "status": "BOOKED",
          "timestamp": "2019-08-24T14:50:00Z"
        }
      ]
    }
  ]
}

Case 2 - overdelivery, collect, discard, overdelivery, collect

This use case is similar to use case 1, except that the initially recorded recevied quantity of 3 KOL is immediately collected. The later Discard resolutions then can only be performed after adjusting the initial Collect.

The following operations are performed by the user:

1. Setting received quantity to 3 KOL
2. Booking a Collect of 3 KOL
3. Booking a Discard of 2 KOL together with a -2 KOL adjustment of the Collect
4. Booking another Discard of 1 KOL together with a -1 KOL adjustment of the Collect
5. Updating the received quantity to 5 KOL
6. Booking a Collect of 2 KOL

{
  "id": "635f9c9f5fc3a61ae8df7861",
  "product_id": "635f9ca66496bb9e6bb94f44",
  "unit": {
    "value": 6,
    "unit": "QUANTITY_PIECES"
  },
  "custom_unit_id": "635fb71a67743cd6f905a124",
  "expected_number_of_units": 2,
  "received_number_of_units": 5,
  "resolved_number_of_units": 5,
  "received_values_change_log": [
    // 1 - Setting received quantity to `3 KOL`
    {
      "id": "635fb73267743cd6f905a131",
      "type": "SET_RECEIVED_NUMBER_OF_UNITS",
      "details": {
        "@type": "SetReceivedNumberOfUnitsChangeDetail",
        "new_received_number_of_units": 3,
        "unit": {
          "value": 6,
          "unit": "QUANTITY_PIECES"
        },
        "custom_unit_id": "635fb71a67743cd6f905a124",
        "delta_to_previous_quantity": {
          "number_of_delta_units": 3,
          "delta_unit": {
            "value": 6,
            "unit": "QUANTITY_PIECES"
          },
          "custom_unit_id": "635fb71a67743cd6f905a124"
        },
        "delta_to_expected_quantity": {
          "number_of_delta_units": 1,
          "delta_unit": {
            "value": 6,
            "unit": "QUANTITY_PIECES"
          },
          "custom_unit_id": "635fb71a67743cd6f905a124"
        }
      },
      "timestamp": "2019-08-24T14:10:00Z"
    },

    // 5 - Updating the received quantity to `5 KOL`
    {
      "id": "635fb73267743cd6f905a135",
      "type": "SET_RECEIVED_NUMBER_OF_UNITS",
      "details": {
        "@type": "SetReceivedNumberOfUnitsChangeDetail",
        "new_received_number_of_units": 5,
        "unit": {
          "value": 6,
          "unit": "QUANTITY_PIECES"
        },
        "custom_unit_id": "635fb71a67743cd6f905a124",
        "delta_to_previous_quantity": {
          "number_of_delta_units": 2,
          "delta_unit": {
            "value": 6,
            "unit": "QUANTITY_PIECES"
          },
          "custom_unit_id": "635fb71a67743cd6f905a124"
        },
        "delta_to_expected_quantity": {
          "number_of_delta_units": 3,
          "delta_unit": {
            "value": 6,
            "unit": "QUANTITY_PIECES"
          },
          "custom_unit_id": "635fb71a67743cd6f905a124"
        }
      },
      "timestamp": "2019-08-24T14:50:00Z"
    }
  ],
  "resolutions": [
    // 2 - Booking a `Collect` of `3 KOL`
    {
      "id": "635fb73267743cd6f905a132",
      "affected_stock": {
        "number_of_units": 3,
        "unit": {
          "value": 6,
          "unit": "QUANTITY_PIECES"
        },
        "custom_unit_id": "635fb71a67743cd6f905a124"
      },
      "details": {
        "@type": "GoodsInItemCollectResolutionDetails"
      },
      "status": "BOOKED",
      "status_log": [
        {
          "status": "PLANNED",
          "timestamp": "2019-08-24T14:20:00Z"
        },
        {
          "status": "BOOKED",
          "timestamp": "2019-08-24T14:20:00Z"
        }
      ],
      "adjustments": [
        // 3b - `-2 KOL` adjustment of the `Collect` due to `Discard` of `2 KOL`
        {
          "id": "635fb73267743cd6f905a133b",
          "type": "DECREASE",
          "affected_stock": {
            "number_of_units": 2,
            "unit": {
              "value": 6,
              "unit": "QUANTITY_PIECES"
            },
            "custom_unit_id": "635fb71a67743cd6f905a124"
          },
          "due_to": {
            "item_id": "635f9c9f5fc3a61ae8df7861",
            "resolution_id": "635fb73267743cd6f905a133"
          },
          "status": "BOOKED",
          "status_log": [
            {
              "status": "PLANNED",
              "timestamp": "2019-08-24T14:30:00Z"
            },
            {
              "status": "BOOKED",
              "timestamp": "2019-08-24T14:30:00Z"
            }
          ]
        },

        // 4b - `-1 KOL` adjustment of the `Collect` due to `Discard` of `1 KOL`
        {
          "id": "635fb73267743cd6f905a134b",
          "type": "DECREASE",
          "affected_stock": {
            "number_of_units": 1,
            "unit": {
              "value": 6,
              "unit": "QUANTITY_PIECES"
            },
            "custom_unit_id": "635fb71a67743cd6f905a124"
          },
          "due_to": {
            "item_id": "635f9c9f5fc3a61ae8df7861",
            "resolution_id": "635fb73267743cd6f905a134"
          },
          "status": "BOOKED",
          "status_log": [
            {
              "status": "PLANNED",
              "timestamp": "2019-08-24T14:40:00Z"
            },
            {
              "status": "BOOKED",
              "timestamp": "2019-08-24T14:40:00Z"
            }
          ]
        }
      ]
    },

    // 3a - Booking a `Discard` of `2 KOL`
    {
      "id": "635fb73267743cd6f905a133",
      "affected_stock": {
        "number_of_units": 2,
        "unit": {
          "value": 6,
          "unit": "QUANTITY_PIECES"
        },
        "custom_unit_id": "635fb71a67743cd6f905a124"
      },
      "reason": {
        "@type": "PlatformDefinedGoodsInExceptionalResolutionReason",
        "name": "STATE_OF_GOODS"
      },
      "details": {
        "@type": "GoodsInItemDiscardResolutionDetails"
      },
      "status": "BOOKED",
      "status_log": [
        {
          "status": "PLANNED",
          "timestamp": "2019-08-24T14:30:00Z"
        },
        {
          "status": "BOOKED",
          "timestamp": "2019-08-24T14:30:00Z"
        }
      ]
    },

    // 4a - Booking another `Discard` of `1 KOL`
    {
      "id": "635fb73267743cd6f905a134",
      "affected_stock": {
        "number_of_units": 1,
        "unit": {
          "value": 6,
          "unit": "QUANTITY_PIECES"
        },
        "custom_unit_id": "635fb71a67743cd6f905a124"
      },
      "reason": {
        "@type": "PlatformDefinedGoodsInExceptionalResolutionReason",
        "name": "STATE_OF_GOODS"
      },
      "details": {
        "@type": "GoodsInItemDiscardResolutionDetails"
      },
      "status": "BOOKED",
      "status_log": [
        {
          "status": "PLANNED",
          "timestamp": "2019-08-24T14:40:00Z"
        },
        {
          "status": "BOOKED",
          "timestamp": "2019-08-24T14:40:00Z"
        }
      ]
    },

    // 6 - Booking a `Collect` of `2 KOL`
    {
      "id": "635fb73267743cd6f905a136",
      "affected_stock": {
        "number_of_units": 2,
        "unit": {
          "value": 6,
          "unit": "QUANTITY_PIECES"
        },
        "custom_unit_id": "635fb71a67743cd6f905a124"
      },
      "details": {
        "@type": "GoodsInItemCollectResolutionDetails"
      },
      "status": "BOOKED",
      "status_log": [
        {
          "status": "PLANNED",
          "timestamp": "2019-08-24T15:00:00Z"
        },
        {
          "status": "BOOKED",
          "timestamp": "2019-08-24T15:00:00Z"
        }
      ]
    }
  ]
}

Case 3 - overdelivery, discard, revert discard, discard, underdelivery

The following JSON payload shows a GoodsInItem with an expected quantity of 2 KOL (where one KOL consists of 6 pcs) after the following operations have been performed by the user:

1. Setting received quantity to 3 KOL
2. Booking a Discard of 2 KOL due to damaged goods
3. Reverting the Discard (that is, adjust it to effectively zero units)
4. Booking another Discard of 1 KOL due to damaged goods
5. Updating the received quantity to 1 KOL

{
  "id": "635f9c9f5fc3a61ae8df7861",
  "product_id": "635f9ca66496bb9e6bb94f44",
  "unit": {
    "value": 6,
    "unit": "QUANTITY_PIECES"
  },
  "custom_unit_id": "635fb71a67743cd6f905a124",
  "expected_number_of_units": 2,
  "received_number_of_units": 1,
  "resolved_number_of_units": 1,
  "received_values_change_log": [
    // 1 - Setting received quantity to `3 KOL`
    {
      "id": "635fb73267743cd6f905a131",
      "type": "SET_RECEIVED_NUMBER_OF_UNITS",
      "details": {
        "@type": "SetReceivedNumberOfUnitsChangeDetail",
        "new_received_number_of_units": 3,
        "unit": {
          "value": 6,
          "unit": "QUANTITY_PIECES"
        },
        "custom_unit_id": "635fb71a67743cd6f905a124",
        "delta_to_previous_quantity": {
          "number_of_delta_units": 3,
          "delta_unit": {
            "value": 6,
            "unit": "QUANTITY_PIECES"
          },
          "custom_unit_id": "635fb71a67743cd6f905a124"
        },
        "delta_to_expected_quantity": {
          "number_of_delta_units": 1,
          "delta_unit": {
            "value": 6,
            "unit": "QUANTITY_PIECES"
          },
          "custom_unit_id": "635fb71a67743cd6f905a124"
        }
      },
      "timestamp": "2019-08-24T14:10:00Z"
    },

    // 5 - Updating the received quantity to `1 KOL`
    {
      "id": "635fb73267743cd6f905a135",
      "type": "SET_RECEIVED_NUMBER_OF_UNITS",
      "details": {
        "@type": "SetReceivedNumberOfUnitsChangeDetail",
        "new_received_number_of_units": 1,
        "unit": {
          "value": 6,
          "unit": "QUANTITY_PIECES"
        },
        "custom_unit_id": "635fb71a67743cd6f905a124",
        "delta_to_previous_quantity": {
          "number_of_delta_units": -2,
          "delta_unit": {
            "value": 6,
            "unit": "QUANTITY_PIECES"
          },
          "custom_unit_id": "635fb71a67743cd6f905a124"
        },
        "delta_to_expected_quantity": {
          "number_of_delta_units": -1,
          "delta_unit": {
            "value": 6,
            "unit": "QUANTITY_PIECES"
          },
          "custom_unit_id": "635fb71a67743cd6f905a124"
        }
      },
      "timestamp": "2019-08-24T14:50:00Z"
    }
  ],
  "resolutions": [
    // 2 - Booking a `Discard` of `2 KOL` due to damaged goods
    {
      "id": "635fb73267743cd6f905a132",
      "affected_stock": {
        "number_of_units": 2,
        "unit": {
          "value": 6,
          "unit": "QUANTITY_PIECES"
        },
        "custom_unit_id": "635fb71a67743cd6f905a124"
      },
      "reason": {
        "@type": "PlatformDefinedGoodsInExceptionalResolutionReason",
        "name": "STATE_OF_GOODS"
      },
      "details": {
        "@type": "GoodsInItemDiscardResolutionDetails"
      },
      "status": "BOOKED",
      "status_log": [
        {
          "status": "PLANNED",
          "timestamp": "2019-08-24T14:20:00Z"
        },
        {
          "status": "BOOKED",
          "timestamp": "2019-08-24T14:20:00Z"
        }
      ],
      "adjustments": [
        // 3 - Reverting the `Discard`
        {
          "id": "635fb73267743cd6f905a133",
          "type": "DECREASE",
          "affected_stock": {
            "number_of_units": 2,
            "unit": {
              "value": 6,
              "unit": "QUANTITY_PIECES"
            },
            "custom_unit_id": "635fb71a67743cd6f905a124"
          },
          "reason": {
              "@type": "PlatformDefinedGoodsInResolutionAdjustmentReason",
              "name": "HUMAN_ERROR"
          },
          "status": "BOOKED",
          "status_log": [
            {
              "status": "PLANNED",
              "timestamp": "2019-08-24T14:30:00Z"
            },
            {
              "status": "BOOKED",
              "timestamp": "2019-08-24T14:30:00Z"
            }
          ]
        }
      ]
    },

    // 4 - Booking another `Discard` of `1 KOL` due to damaged goods
    {
      "id": "635fb73267743cd6f905a134",
      "affected_stock": {
        "number_of_units": 1,
        "unit": {
          "value": 6,
          "unit": "QUANTITY_PIECES"
        },
        "custom_unit_id": "635fb71a67743cd6f905a124"
      },
      "reason": {
        "@type": "PlatformDefinedGoodsInExceptionalResolutionReason",
        "name": "STATE_OF_GOODS"
      },
      "details": {
        "@type": "GoodsInItemDiscardResolutionDetails"
      },
      "status": "BOOKED",
      "status_log": [
        {
          "status": "PLANNED",
          "timestamp": "2019-08-24T14:40:00Z"
        },
        {
          "status": "BOOKED",
          "timestamp": "2019-08-24T14:40:00Z"
        }
      ]
    }
  ]
}

Case 4 - regular delivery, collect, reset to planned, overdelivery, collect + discard

The following JSON payloads shows a GoodsInItem with an expected quantity of 10 pcs after the following operations have been performed by the user:

1. Set received quantity to 10 pcs
2. Book a Collect of all 10 pcs
3. Reset of the goods-in to PLANNED
4. Set received quantity to 12 pcs
5. Book a Collect for 10 pcs
6. Book a Discard for 2 pcs

{
  "id": "635f9c9f5fc3a61ae8df7861",
  "product_id": "635f9ca66496bb9e6bb94f44",
  "unit": {
    "value": 1,
    "unit": "QUANTITY_PIECES"
  },
  "expected_number_of_units": 10,
  "received_number_of_units": 12,
  "resolved_number_of_units": 12,
  "received_values_change_log": [
    // 1 - Setting received quantity to `10 pcs`
    {
      "id": "644a8908cd019709e4a27953",
      "type": "SET_RECEIVED_NUMBER_OF_UNITS",
      "details": {
        "@type": "SetReceivedNumberOfUnitsChangeDetail",
        "new_received_number_of_units": 10,
        "unit": {
          "value": 1,
          "unit": "QUANTITY_PIECES"
        },
        "delta_to_previous_quantity": {
          "number_of_delta_units": 10,
          "delta_unit": {
            "value": 1,
            "unit": "QUANTITY_PIECES"
          }
        },
        "delta_to_expected_quantity": {
          "number_of_delta_units": 0,
          "delta_unit": {
            "value": 1,
            "unit": "QUANTITY_PIECES"
          }
        }
      },
      "timestamp": "2019-08-24T14:10:00Z"
    }

    // 3 - Reset goods-in to PLANNED
    {
      "id": "644a8e708fdb955f3cc69cb5",
      "type": "RESET_TO_PLANNED",
      "details": {
        "@type": "ResetToPlannedChangeDetail",
      },
      "timestamp": "2019-08-24T14:30:00Z"
    }

    // 4 - Setting received quantity to `12 pcs`
    {
      "id": "644a8e7c9f304ffb76e102ae",
      "type": "SET_RECEIVED_NUMBER_OF_UNITS",
      "details": {
        "@type": "SetReceivedNumberOfUnitsChangeDetail",
        "new_received_number_of_units": 12,
        "unit": {
          "value": 1,
          "unit": "QUANTITY_PIECES"
        },
        "delta_to_previous_quantity": {
          "number_of_delta_units": 12,
          "delta_unit": {
            "value": 1,
            "unit": "QUANTITY_PIECES"
          }
        },
        "delta_to_expected_quantity": {
          "number_of_delta_units": 2,
          "delta_unit": {
            "value": 1,
            "unit": "QUANTITY_PIECES"
          }
        }
      },
      "timestamp": "2019-08-24T14:40:00Z"
    }
  ],
  "resolutions": [
    // 2 - Booking a `Collect` of `10 pcs`
    {
      "id": "644a89bddfe12d88c0433adc",
      "affected_stock": {
        "number_of_units": 10,
        "unit": {
          "value": 1,
          "unit": "QUANTITY_PIECES"
        }
      },
      "details": {
        "@type": "GoodsInItemCollectResolutionDetails"
      },
      "status": "ANNULLED",
      "status_log": [
        {
          "status": "PLANNED",
          "timestamp": "2019-08-24T14:20:00Z"
        },
        {
          "status": "BOOKED",
          "timestamp": "2019-08-24T14:20:00Z"
        },
        {
          // 3 - Reset goods-in to PLANNED causes annullment of previously booked resolutions
          "status": "ANNULLED",
          "timestamp": "2019-08-24T14:30:00Z"
        }
      ],
      "adjustments": [
        // 3 - Reset goods-in to PLANNED causes annullment of previously booked resolutions
        {
          "id": "644a8aa84669fd2b1186e9ad",
          "type": "DECREASE",
          "affected_stock": {
            "number_of_units": 10,
            "unit": {
              "value": 1,
              "unit": "QUANTITY_PIECES"
            }
          },
          "status": "BOOKED",
          "status_log": [
            {
              "status": "PLANNED",
              "timestamp": "2019-08-24T14:30:00Z"
            },
            {
              "status": "BOOKED",
              "timestamp": "2019-08-24T14:30:00Z"
            }
          ]
        }
      ]
    }

    // 5 - Booking a `Collect` of `10 pcs`
    {
      "id": "644a899c889e61f23f436c8b",
      "affected_stock": {
        "number_of_units": 10,
        "unit": {
          "value": 1,
          "unit": "QUANTITY_PIECES"
        }
      },
      "details": {
        "@type": "GoodsInItemCollectResolutionDetails"
      },
      "status": "BOOKED",
      "status_log": [
        {
          "status": "PLANNED",
          "timestamp": "2019-08-24T14:50:00Z"
        },
        {
          "status": "BOOKED",
          "timestamp": "2019-08-24T14:50:00Z"
        }
      ]
    }

    // 6 - Booking a `Discard` of `2 pcs`
    {
      "id": "644a89d991790cf2ea45b29a",
      "affected_stock": {
        "number_of_units": 2,
        "unit": {
          "value": 1,
          "unit": "QUANTITY_PIECES"
        }
      },
      "reason": {
        "@type": "PlatformDefinedGoodsInExceptionalResolutionReason",
        "name": "NOT_ORDERED"
      },
      "details": {
        "@type": "GoodsInItemDiscardResolutionDetails"
      },
      "status": "BOOKED",
      "status_log": [
        {
          "status": "PLANNED",
          "timestamp": "2019-08-24T15:00:00Z"
        },
        {
          "status": "BOOKED",
          "timestamp": "2019-08-24T15:00:00Z"
        }
      ]
    },
  ]
}

• GoodsOut
  • Cancellation requests
    • By goods-out staff (GOS)
    • From higher-level business process (HLP)
    • Cancellation workflow/logic:
    • Life-cycle / Active

GoodsOut

Cancellation requests

The cancellation of a goods-out can be desired by different actors for various reasons.

By goods-out staff (GOS)

There are various reasons why the person asked to process the goods-out may want it to get canceled. For example, there may not be enough stock to pick or packaging material. There may not be enough space or time to perform the picking and packing. There may be some power outage. Some machine needed (e.g., a label printer, a pallet jack) may be broken or otherwise not available.

As long as the GoodsOut is still unconfirmed, the goods-out staff could simply reject it. But once it has been confirmed, that is no longer possible. And simply canceling the GoodsOut from the "processing side" is not allowed as goods-out are "depending business processes" and thus their cancellation must be controlled via their "parent process".

From higher-level business process (HLP)

A high-level business process that is parent of one or more goods-out may want those to get canceled because it may be canceled itself or because the existing goods-out are not needed/wanted anymore. For example when a different location shall perform the goods-out or when a delivery is to be split.

As long as the GoodsOut is not yet "in process", it could simply be canceled as the parent process has the right to do so. But when picking has already started, this would cause a problem with the picked stock. The goods-out staff has picked things and they are not "in stock" anymore. Automatically booking them back to "in stock" would not cause them to actually move "in the real world". The goods-out staff would also not really get any notification, "his" GoodsOut would simply not be shown in the UI anymore.

Cancellation workflow/logic:

Thus, the following workflow/logic should be used when requesting and performing cancellations:

• GOS wants to cancel

  • GOS issues request describing the wish to cancel
  • HLP accepts or rejects the request
  • If rejected
    • Workflow is finished
  • If accepted and GoodsOut is still UNCONFIRMED or CONFIRMED
    • GoodsOut can directly get canceled, "accept" can be sent as secondary+before to "cancel"
  • If accepted and GoodsOut is already IN_PROCESS
    • GOS must trigger cancellation by executing "performFullCancellation"

• HLP wants to cancel

  • HLP issues request describing the need/wish to cancel
  • GOS accepts the request
    • We may want to allow GOS to reject, but that would need some kind of setting or user right that allows this.
  • If rejected (once we allow this)
    • Workflow is finished
  • If accepted and GoodsOut is still UNCONFIRMED or CONFIRMED
    • GoodsOut can directly get canceled, "accept" can be sent as secondary+before to "cancel"
  • If accepted and GoodsOut is already IN_PROCESS
    • GoodsOut can get canceled, "accept" can be set as part of "performFullCancellation"

Life-cycle / Active

A cancellation request has a simple life cycle consisting of the states REQUESTED, ACCEPTED, REJECTED and WITHDRAWN.

Additionally, it has a cancellation_performed flag. This flag is not a state as it does not represent a property of the request but of the goods-out.

Requests are considered to be "active" when they are in state PENDING or ACCEPTED and their cancellation_performed flag is false.

Introduction (Spec)

This documentation describes the high-level architecture of the enfore Ledger-API.

The enfore Ledger-API is provided by the enfore platform to be convenient to use for ledger use cases, for example when integrating with an external ledger system.

The API consists of multiple modules that allow

• notification about and querying of accounts
• notification about and querying of booking periods
• notification about and querying of transactions

The exact set of modules and their capabilities will evolve over time, the initial API version will only support a very limited set of use cases.

Use cases

The aim of the Ledger-API is to be useful for implementing use cases related to observing ledger/accounting data recorded in the enfore platform and copying/transmission of such data to third party systems.

For now, the API only supports

• Direct, immediately executed queries against the enfore ledger backend
• Subscribing to notifications about accounts, booking periods and transactions

Domain model

The "ledger" domain model of the enfore platform consists of objects that can be separated into three groups: transactions, accounts, and booking periods.

A transaction is a record of the movement of a monetary amount from one account to another. An account is a holder of a monetary amount (aka balance) that is modified by transactions adding to or removing from that balance. Booking periods are timespans that are used to group transactions based on the need of the business rather than a general calendar (see "business day" vs. "calendar day")

Accounts

From a technical point of view, an account is simply a container for a monetary amount called balance. From an accounting point of view, accounts have meaning based on their type and additional properties.
The accounts used by an organization make up its "chart of accounts" (COA) - a financial, organizational tool that provides an index of every account in an accounting system.
Some of these accounts appear on the balance sheets of an organization. They give a summary of the financial balances of the organization, a snapshot of an organization's financial condition, so to speak.
The accounts of the balance sheet represent liabilities, assets and ownership equity of the organization. In our domain model most of them use the Type BalanceSheetAccount.
Some accounts for assets or liabilities are used for PaymentTransactions. We call them "money accounts". Currently there are two kinds of money accounts in our domain model:

• certain BalanceSheetAccounts
• CashAccounts

Other "money accounts" will be added later, e.g. BankAccounts.
Other accounts in the COA represent revenue and expenses of the organization.
Furthermore there are accounts representing business partners in their roles as a creditor or debtor, as explained below. They can be seen as sub-accounts of the "accounts receivable" and "accounts payable" accounts of the COA.
Using different account types allows to to define transactions that only work on specific types of accounts.

Balance-sheet accounts

As mentioned, most accounts on the balance sheet use the type BalanceSheetAccount. Typical examples:

• the asset account for "accounts receivable"
• the liability account for "accounts payable"
• the asset account for cash in transit
• the asset account for transit items like tip or escrow sales
• the account for the liabilities caused by voucher sales

The latter is an example for a BalanceSheetAccount that can be used as money account.
Many of the BalanceSheetAccounts are not used by any workflows in enforePOS yet, and the available accounts heavily depend on the country of the organization. In a country like Germany, where detailed standardized Charts of Accounts exist, the number of BalanceSheetAccounts can be huge. In other countries, where only coarse specifications for a Chart of Accounts exist, the number of BalanceSheetAccounts provided by the domain model will be small.

Cash accounts

Cash accounts are used to track physical money (that is, coins and bank notes). In the real world, they are therefore represented by some kind of container like a waiter's wallet or a strongbox.

The enfore platform differentiates between three types of cash accounts based on the "container type":

• WALLET - a wallet is only available as personalized cash containers belonging to a specific staff member like waiter
• CASH_DRAWER - always located at a particular cash register, either assigned to that register or to a specific staff member; in the former case it is used by all staff members, in the latter case only be the assigned staff member
• VAULT - for cash containers that belong to a service location rather than a specific staff member or register and are not used used for register-level transactions (e.g. sales and refunds).
• PETTY_CASH - for cash containers that belong to a service location rather than a specific staff member or register and are not used used for register-level transactions (e.g. sales and refunds).

There are some additional constraints imposed by the enfore plaform regarding management of cash containers:

1. A Staff member's personalized cash container is managed as a cash account with container type WALLET or CASH_DRAWER on a "per location"-basis. That means, if the staff member works at more than one location (e.g., a waiter switching between different branches of a chain), a separate cash account exists for each location and money must be explicitly transferred between those by recording an appropriate money transfer.
2. Staff members that are assigned a such cash account cannot perform cash-related operations on registers that are assigned a CASH_DRAWER-type cash account. This is to avoid the ambiguity of "where does the money go/come from" when that staff member sells/refunds something via that register.
3. CashAccounts of type VAULT can't be used to record PaymentTransactions for revenue, only MoneyTransfers and PaymentTransactions for expenses can be recorded.

Expense accounts

ExpenseAccounts track the expenses of an organization. Depending on the COA being used, there could be one general expense account or many expense accounts where each account represents a particular kind of expense (e.g. travel cost, education etc.).

Income accounts

IncomeAccounts track the revenue made by an organization. Currently they are not exposed by the domain model.

Creditor accounts

A creditor' refers to the party that has delivered a product, service or loan, and is owed money by the organization. A creditor account tracks the credit amounts and their reconciliation for a specific creditor. Creditor accounts are assigned to staff members and suppliers (contacts with a staff or supplier role).
If a creditor in a business process involving transactions is not known (like in expenses made by a supplier not tracked by the organization), many systems use the "accounts payable" account instead of a CreditorAccount. In our model an "Miscellaneous Supplier" with an assigned CreditorAccount is used. This allows to use CreditorAccounts in transactions in a type-safe way and also allows to require the associated fields in the domain model for transactions using CreditorAccounts.

Debtor accounts

A debtor is a party who owes money to the organization. A debtor account tracks the owed amounts and their reconciliation for a specific debtor. Debtor accounts are assigned to customers (contacts with a customer role) or alternative payers (contacts with an alternative payer role).
Usually a DebtorAcount is used for specific customers (or alternative payers) as the debtor.
If a debtor in a business process involving transactions is not known (like in sales to an unknown customer), many systems use the "accounts receivable" account instead of a DebtorAccount. In our model an "Anonymous Customer" with an assigned DebtorAccount is used. This allows to use DebtorAccounts in transactions in a type-safe way and also allows to require the associated fields in the domain model for transactions using DebtorAccounts.

Tracking accounts

Explained in the section about booking periods.

Transactions

Transactions move monetary amounts between accounts. Depending on the types of the accounts involved as well as the meaning of the transaction, different transaction types are used. All transaction types share the same set of basic information (such as number, amount, recording/processing timestamp and by whom/where they were recorded) but have additional field to holds the information necessary for the specific type of transaction.

Money transfers

MoneyTransfers are transactions that differ fundamentally from other transactions in two aspects:

• they always transfer money between two accounts on the balance sheet (BalanceSheetAccounts and money accounts)
• they do not have "items", so the whole transfer fulfills a single purpose

The two accounts between them money is transferred are given by the fields active_account and target_account. The former is the account where the transfer is recorded. If this account is a CashAccount with a TSE, this TSE is used to cover the transaction. Depending on the value of the field direction money is either moved away from that account (direction OUTGOING) to the target_account or moved into that account (direction INCOMING) from the target_account.

Transfer of money can be recorded as one MoneyTransfer of type SINGLE or as a pair of MoneyTransfers with types ORIGIN and CONTINUATION that reference each other through the counterpart field and can be recorded at different points in time. If the target_account of a CONTINUATION type MoneyTransfer is a CashAccount with a TSE, this TSE ist used to cover the transaction.

Depending on the type of MoneyTransfers, it is possible that at least one of two accounts in the transfer is empty temporarily:

• type SINGLE: both accounts are set from the beginning
• type ORIGIN: target_account may be empty until the matching CONTINUATION is recorded
• type CONTINUATION: both accounts are set from the beginning

Expense transactions

ExpenseTransactions track expenses of the organization. They contain one or more ExpenseItems, each of them representing a single purchase of goods or services made by the organization. Each ExpenseItem references an ExpenseAccount, and the whole transactions references a CreditorAccount, representing the person or organization that needs to be paid for the received goods or services. So in total the ExpenseTransaction moves money between one or more ExpenseAccounts and a CreditorAccount. If the transactions has the type "CREDIT", the organization owes money to the creditor and the CreditorAccount is charged with a negative amount. If the type is "DEBIT", it's the other way around. This represents a reversal of a prior expense.
Currently ExpenseTransactions in enforePOS only apear as simple transactions with a single item and always directly paid by cash and using the CreditorAccount of the "Miscellaneous Supplier".

IncomeTransactions

IncomeTransactions track revenue made by the organization. In total they move money between one or more IncomeAccounts and a DebtorAccount. A typical use case for an IncomeTransaction is a sales invoice. Additionally, income transactions are created when handling cash overhangs during business day management.

For income transactions created for sales invoices, more information can be accessed via the ERP-API.

Payment transactions

PaymentTransactions represent payments for "payable" transactions (ExpenseTransactions or IncomeTransactions) and those other transactions are "paid by" the former. They always move money between a money account and a DebtorAccount or CreditorAccount.
So if we look on an ExpenseTransaction and a PaymentTransaction that pays it, together they move money between one or more ExpenseAccounts and a money account, using a CreditorAccount as intermediate account, that keeps track of the liability that exists in the time between recording the expense and recording the payment.
In the same way, an IncomeTransaction and the PaymentTransaction that pays it together move money between one or more IncomeAccounts and a money account, using a DebtorAccount as intermediate account, that keeps track of the In general the relation between PaymentTransactions and their paid transactions is m:n, in most cases either 1:1, 1:n or m:1. To represent these relationships, PaymentTransactions have an array of "ReferencedTransactions" and ExpenseTransactions or IncomeTransactions have an array of "payments".
Both are dedicated data structures that hold the necessary information.

Payments

Payment structures are used in transactions paid by other transactions, to record how much was paid via what transaction at what point in time. Note that a transaction can be paid for in parts, resulting in multiple Payment structures being present in the paid transaction.

This kind of structure is used by expense transactions and by inceome transactions.

For each payment that is made for a transaction, that transaction will received a Payment structure with:

Referenced transactions

ReferencedTransaction structures are used in transactions that are payments for other transactions, to record how much of the transaction was payment for the other transaction. As a single transaction can be payment for multiple other transactions, multiple ReferencedTransaction structures may be present in the paying transaction.

This kind of structure is used by payment transactions and by balance-sheet transactions that represent payments.

For each transaction that is fully or partially paid for by a transaction, that transaction will received a ReferencedTransaction structure with:

Example

As an example, consider a user recording a cash drawing for an expense. This will create

• an ExpenseTransaction that records money being moved from the CreditorAccount of the supplier to the relevant ExpenseAccount (based on the type of expense)
• a PaymentTransaction that records money being moved from the CashAccount to the CreditorAccount of the supplier

The expense transaction causes the expense's amount to be deducted from the creditor account (meaning the creditor is owned that amount) and added to the expense account (meaning an expense occurred).

The payment transaction causes the payment's amount to be deducted from the cash account (as money was taken out) and added to the creditor account (settling the liability caused by the expense transaction).

Both transactions are linked by their Payment/ReferencedTransaction structures to represent that fact that the payment transaction paid for the expense transaction.

Stripped down to the cross references, the expense transaction looks like this:

{
    "id": "et_0001",
    "creditor_account": {
        "account_id": "cra_0002",
        "account_type": "CREDITOR_ACCOUNT"
    },
    "items": [
        {
            "account": {
                "account_id": "ea_0003",
                "account_type": "EXPENSE_ACCOUNT"
            }
        }
    ],
    "payments": [
        {
            "transaction": {
                "transaction_id": "pt_0004",
                "transaction_type": "PAYMENT_TRANSACTION"
            }
        }
    ]
}

And the payment transaction looks like this:

{
    "id": "pt_0004",
    "money_account": {
        "account_id": "caa_0005",
        "account_type": "CASH_ACCOUNT"
    },
    "payee_account": {
        "account_id": "cra_0002",
        "account_type": "CREDITOR_ACCOUNT"
    },
    "referenced_transactions": [
        {
            "transaction": {
                "transaction_id": "et_0001",
                "transaction_type": "EXPENSE_TRANSACTION"
            }
        }
    ]
}

Booking Periods

Accounts keep a balance, that reflects the total effect of all transactions made on this account. Booking periods keep track of these balances over time. They also accumulate some more KPIs that currently are not exposed through the ledger API.
Booking periods can be started and closed automatically on events, in recurring time frames or based on explicit user actions. They will always record the account balance in different states:

• when the period is created (and the balance is taken over from the closing balance of the prior period)
• when the period is started
• when the period is closed

Though basically every account could use booking periods, they are currently used only on CashAccounts and TrackingAccounts.

Booking periods of TrackingAccounts

Tracking Accounts never appear as account in transactions, they only accumulate the effect of transactions made on other accounts. They are automatically created for:

• POSLocations
• Staff members working as cashiers at a POSLocation
• Cash register devices

Every transaction made at a particular POSLocation will always reference a device and a staff member, and these are assigned to a POSLocation, so every such transaction can be assigned to the current booking period of the tracking accounts of these objects. They modify the balance of these tracking accounts and their booking periods.
In the enforePOS application the booking periods are represented by the register or staff member reports in the accounting UI. Their life cycles exactly match those of the business days or cashier shifts of the owners of the tracking accounts.

Booking periods of CashAccounts

Cash register devices and staff members working as cashiers both can own cash accounts. If they do, enforePOS automatically creates booking periods not only for their tracking accounts, but also for their cash accounts. Their life cyle is exactly in sync with the life cycle of the tracking accounts.
CashAccounts add one feature to booking periods, because they might require counting of cash money at times. The result of that counting might differ from the current balance of the booking period, that is calculated from the recorded transactions. enforePOS requires that these differences are reconciled by recording a suitable transaction before the period is closed. To keep track of that difference, the booking period provides two additional balances: the manual_end_balance for the total amount of the final counting and the closing_difference for the amount of the transaction that is recorded to make the current balance of the period match the manual_end_balance.

Introduction (Spec)

This documentation describes the high-level architecture of the enfore Organization Structure & Configuration-API.

The enfore Organization Structure & Configuration-API is provided by the enfore platform to be allow programmatic setup/modification of the structural elements of an organization as represented in the enforePOS platform.

The API consists of multiple modules that allow

• notification about, querying and creation/update of POS sales channels
• notification about, querying and creation/update of service locations

The exact set of modules and their capabilities will evolve over time, the initial API version will only support a very limited set of use cases.

Use cases

Domain model

The domain model of the enfore Organization Structure & Configuration-API consists of the core objects:

• POSSalesChannel
• ServiceLocation
• ProcessingLocation
• StorageLocation

The enfore platform uses sales channels as a concept to model different ways via wich to sell products to customer. A POSSalesChannel is a sales channel that is realized by a physical store location. Other types of sales channels are used to represent sales via online channels such as the enfore OnlinePresence, Amazon, Ebay or a custom online store.

Every direct physical interaction with customers is performed at a ServiceLocation. As such a service locations represents a physical place that customers can access and must have a name and an address.

There is a 1:1 relationship between POSSalesChannels and ServiceLocations. That is, there is exactly one ServiceLocation for each POSSalesChannel and vice versa. This combination is also called a "POS location", for example in the enforePOS client application UI.

In a POS location, the sales channel is used to configure how products are sold (e.g., is pickup possible). Whereas the service location is used to configure how the sale is recorded (e.g., cash management settings, settings for how revenue is booked) and fulfilled (e.g., where are productions, pickups and deliveries performed).

For the production of items and the preparation of pickup and delivery operations, a ProcessingLocation is needed. These processing locations always belong to a specific service location, even though they might have a different phyiscal location (e.g., a garage where bicycles are built that are sold from a store across the street).

The ProcessingLocation holds configuration for the production, pickup and delivery processes. For example, what type of tracking is enabled. Or which documents are printed and what printer to use.

TBD: What about inconsistencies between SalesChannel and AssemblyLocation settings. E.g., SalesChannel states "Delivery splip is printed" but AssemblyLocation does not have this setting and might not even have a printer configured?

A StorageLocation is a place where the organization stores physical goods such as inventory items or raw materials.

Introduction (Spec)

This documentation describes the high-level architecture of the enfore Promotions-API.

The enfore Promotions-API is provided by the enfore platform to allow management of promotions and loyalty programs as well as related objects such as sales vouchers.

The API consists of multiple modules that handle

• External Loyalty Programs
• Sales Voucher Gift Cards
• Sales Voucher Product Vouchers
• Sales Voucher Category Vouchers

Introduction (Spec)

This documentation describes the high-level architecture of the enfore Reservation-API.

The enfore Reservation-API is TBD

Introduction (Spec)

This documentation describes the high-level architecture of the enfore Sales and Purchasing API.

The enfore Sales and Purchasing API is provided by the enfore platform to be convenient to use for managing sales orders in the "Retail" vertical, for example when integrating with an external system such as SAP or Dynamics.

Use cases

The aim of the Sales and Purchasing-API is to be useful for implementing use cases related to sales in the "Retail" vertical.

Initially, the API will only support a small set of use cases:

• Fetching sales order information
• Receiving notifications about newly created sales orders
• Creation of new sales orders
• Updating status of sales orders (and related entities such as productions and fulfillments)

Fetching sales order information

A main use case of the Sales and Purchasing-API is the ability to page through existing sales orders.

For paging through existing sales orders, the Sales and Purchasing-API provides the endpoint GET /org/{org-id}/sales-orders/. That endpoint follows the normal paging-pattern of the enfore-APIs in that the client must specifiy a time-window via from and to and can then page within that window using offset and limit.

For example, the following requests can be used to access the first 200 sales orders whose transaction timestamp lies between 1pm and 3pm CEST on May 1st 2019:

• GET /org/{org-id}/sales-orders/?from=2017-05-01T11%3A00%3A00Z&to=2017-05-01T13%3A00%3A00Z&limit=50&offset=0 (fetches items 0 to 49)
• GET /org/{org-id}/sales-orders/?from=2017-05-01T11%3A00%3A00Z&to=2017-05-01T13%3A00%3A00Z&limit=50&offset=50 (fetches items 50 to 99)
• GET /org/{org-id}/sales-orders/?from=2017-05-01T11%3A00%3A00Z&to=2017-05-01T13%3A00%3A00Z&limit=50&offset=100 (fetches items 100 to 149)
• GET /org/{org-id}/sales-orders/?from=2017-05-01T11%3A00%3A00Z&to=2017-05-01T13%3A00%3A00Z&limit=50&offset=150 (fetches items 150 to 199)

Receiving notifications about newly created sales orders

Often times, clients are interested in sales orders that are newly created (for example via the enforePOS client UI). To not have to continously poll the paging endpoint, the sales order API provides a way to register for newly created sales orders via the subscription API.

The event type for newly created sales orders is SALES_ORDERS_NEW.

Whenever a new sales order is created, the registered callback will be invoked with the newly created sales order as payload.

Creation of new sales orders

Another use case for the API is the creation of new sales orders. This can, for example, be used to inject orders received by a third-party shop system into the enfore platform.

Note that sales orders cannot be created directly. Instead, one must first create a sales order draft and the "convert" the draft into a sales order.

Updating status of sales order

Once a sales order has been created (either via the API or via the enfore POS client application), the API provides ways to modify the status of the sales order as well as of related object such as productions and fulillments.

Note that not all status transitions are valid, for example a sales order with a delivery (fulfillment) in status PENDING cannot be set to status COMPLETED. See the domain model documentation for more information on the different status types and how they interact.

Domain model

Introduction (Spec)

This documentation describes the high-level architecture of the enfore Sales Orders API.

The enfore Sales Orders API is provided by the enfore platform to be convenient to use for managing sales orders in the "Retail" vertical, for example when integrating with an external system such as SAP or Dynamics.

Use cases

The aim of the SalesOrders-API is to be useful for implementing use cases related to sales in the "Retail" vertical.

Initially, the API will only support a small set of use cases:

• Fetching sales order information
• Receiving notifications about newly created sales orders
• Creation of new sales orders
• Updating status of sales orders (and related entities such as productions and fulfillments)

Fetching sales order information

A main use case of the SalesOrders-API is the ability to page through existing sales orders.

For paging through existing sales orders, the SalesOrders-API provides the endpoint GET /org/{org-id}/sales-orders/. That endpoint follows the normal paging-pattern of the enfore-APIs in that the client must specifiy a time-window via from and to and can then page within that window using offset and limit.

For example, the following requests can be used to access the first 200 sales orders whose transaction timestamp lies between 1pm and 3pm CEST on May 1st 2019:

• GET /org/{org-id}/sales-orders/?from=2017-05-01T11%3A00%3A00Z&to=2017-05-01T13%3A00%3A00Z&limit=50&offset=0 (fetches items 0 to 49)
• GET /org/{org-id}/sales-orders/?from=2017-05-01T11%3A00%3A00Z&to=2017-05-01T13%3A00%3A00Z&limit=50&offset=50 (fetches items 50 to 99)
• GET /org/{org-id}/sales-orders/?from=2017-05-01T11%3A00%3A00Z&to=2017-05-01T13%3A00%3A00Z&limit=50&offset=100 (fetches items 100 to 149)
• GET /org/{org-id}/sales-orders/?from=2017-05-01T11%3A00%3A00Z&to=2017-05-01T13%3A00%3A00Z&limit=50&offset=150 (fetches items 150 to 199)

Receiving notifications about newly created sales orders

Often times, clients are interested in sales orders that are newly created (for example via the enforePOS client UI). To not have to continously poll the paging endpoint, the sales order API provides a way to register for newly created sales orders via the subscription API.

The event type for newly created sales orders is SALES_ORDERS_NEW.

Whenever a new sales order is created, the registered callback will be invoked with the newly created sales order as payload.

Creation of new sales orders

Another use case for the API is the creation of new sales orders. This can, for example, be used to inject orders received by a third-party shop system into the enfore platform.

Note that sales orders cannot be created directly. Instead, one must first create a sales order draft, that can be processed on the enfore platform to become a sales order.

Updating status of sales order

Once a sales order has been created (either via the API or via the enfore POS client application), the API provides ways to modify the status of the sales order as well as of related object such as productions and fulillments.

Note that not all status transitions are valid, for example a sales order with a delivery (fulfillment) in status PENDING cannot be set to status COMPLETED. See the domain model documentation for more information on the different status types and how they interact.

Domain model

The domain model of the SalesOrders-API consists of the core object types SalesOrderDraft, SalesOrder, Production, Pickup and Delivery.

In essence, a SalesOrderDraft represents an shopping basket in preparation. Once the preparation is done, the draft gets finalized and becomes an active shopping basket. In that state the enfore platform, e.g. the enforePOS application, can process it to become a SalesOrder which tracks the Production and fulfillment (Pickup, Shipment) of the items.

SalesOrderDraft

A SalesOrderDraft represents an active shopping basket in preparation. It can be (almost) freely modified. For example, items may be added or removed and different fulfillment options may be added, removed or updated as necessary.

Sales order draft lifecycle

A sales order draft is essentially a helper object for the creation of a sales order. The normal flow is that a sales order draft is created, items and fulfillments are added, removed, and modified, and then it is finalized to become an active shopping basket. In that state it is SalesOrderDraft anymore.

For example, to create a sales order for two products and with some customer information, the following endpoints would be called (payload/response omitted for brevity):

1. POST /org/{org-id}/sales-order-drafts/ - create a new draft
2. PUT /org/{org-id}/sales-order-drafts/{sales-order-draft-id}/customer - add customer information
3. POST /org/{org-id}/sales-order-drafts/{sales-order-draft-id}/items - add first item
4. POST /org/{org-id}/sales-order-drafts/{sales-order-draft-id}/items - add second item
5. POST /org/{org-id}/sales-order-drafts/{sales-order-draft-id}/patch with SalesOrderDraftFinalizationRequest - finalize draft

Once created, a sales order draft exists until it either is explicitly deleted (via DELETE /org/{org-id}/sales-order-drafts/{sales-order-draft-id}) or until it is finalized.

Operations on a sales order draft

Between the creation of a new sales order draft and its explicit deletion or finalization, clients may perform any number of operations on the draft.

The order of those operations is not limited by the API. For example, one could create a draft, add two items, update the first item, add customer information, add a pickup, remove the second item, update the customer information and only then finalize the draft.

The only limitations are defined by the need to reference items from the fulfillments (pickups and deliveries). While it is possible to add an "empty" fulfillment (one without any items), for an item to be part of a fulfillment, the item has to first exist.

Note that the deletion of an item will remove all references to the item from any fulfillments or other items that currently reference it. This may cause a fulfillment to become "empty". Such fulfillments are removed when the draft is finalized.

SalesOrder

An SalesOrder represents a closed shopping basket or finalized list of items that are to be sold. It may still be unconfirmed and can be canceled, but its "content" (i.e., the items and additional information such as the customer) cannot be changed anymore.

Sales order lifecycle

The lifecycle of a sales order is relatively simple. The initial state is NEW and there are the three final states REJECTED, COMPLETED, and CANCELED. In between, a sales order may be put ON_HOLD at any time:

The meaning of the states is as follows:

Related objects

A sales order might have related object such as productions and fulfillments. Those related objects are separate resource in the API with their own status but the sales order holds links to the objects it is related to as well as an aggregated status.

The production_information field holds a SalesOrderProductionInformation structure that holds links to and an aggregated status for all productions related to the sales order (i.e., productions for items that are sold via the order).

The fulfillment_information field holds a SalesOrderFulfillmentInformation structure that holds links to and an aggregated status for all fulfillments related to the sales order (i.e., pickups and deliveries for items that are sold via the order).

The invoice_information field holds a SalesOrderInvoiceInformation structure that holds links to and an aggregated status for all invoices related to the sales order (i.e., invoices for the sales order or parts of the sales order).

The aggregated status only provides a rough overview on the status of the related objects:

Note that the meaning of "completed" differs depending on the type of related object. For a Production it means that the item has been produced. For an Invoice it means that it has been fully paid.

Also note that related objects are created when the sales order gets CONFIRMED. That is a NEW or REJECTED order won't have related objects (yet).

Edge cases

While SalesOrders-API is focussed on the "retail" vertical and tries to provide a domain-specific view on the business data, the enfore platform provides some advanced features that cannot easily be mapped to this domain-specific view.

For example, for the "gastro" vertical, the platform allows "gastro orders" be be modified, even after they have already been confirmed and partly fulfilled (e.g., somone ordering a second drink). While such "gastro orders" should not be made available via the SalesOrders-API, we currently cannot easily distingush between "retail orders" and "gastro orders". Therefore, in an organization with mixed registers, the SalesOrders-API might expose such "gastro ordes". Those orders can be interacted with via the API just fine, but contrary to regular SalesOrder objects, they may exhibit mutations (e.g., an added item) that normally do not occur.

Production

An Production represents the process of the creation of an item. For example, a "gift basket" item might need to be assembly by a staff member from other products rather than sit pre-packaged on a storage shelf.

Productions are created automatically by the system based on the configuration of the products and organization, they are not configurable via the sales order draft like fulfillments.

A production is always performed at a specific location and covers one or multiple items. Whether two items end up in the same production or not depends on the location as well as organization settings.

A production follows a simple state machine:

The meaning of the states is as follows:

Note that a production's status cannot be modified directly. Instead, the status updates automatically when the status of a production item changes (from PENDING to COMPLETED or back) or when the sales order that the production belongs to gets canceled.

Pickup

A Pickup represents the process of a customer (or someone on behalf of the customer) to pick up one or multiple items from a service location.

Pickups are created based on the SalesOrderDraftPickup objects configured during the draft phase.

A pickup is always performed at a specific location (pickup_location) and may be scheduled to occur during a specific time frame (pickup_time_range).

There may be information about the collector (collector_information), but that isn't a requirement if the business has some other way to ensure items can only be picked up by the right person (e.g., by using a pager or checking the barcode on the pickup slip).

A pickup follows a simple state machine:

The meaning of the states is as follows:

Note that a pickups's status can be modified via the API (via PUT ​/org​/{org-id}​/fulfillments​/pickups​/{pickup-id}​/status) but that it cannot be set to CANCELED that way. A pickup only get's canceled when the sales order that it belongs to gets canceled.

Delivery

A Delivery represents the process of delivering one or multiple items to a customer (or some recipient specified by the customer).

Deliveries are created based on the SalesOrderDraftDelivery objects configured during the draft phase.

A delivery is always performed from a specific location (shipping_location) to a specific address (delivery_addres) and may be scheduled to be delivered during a specific time frame (delivery_time_range).

There may be more information about the collector than just the address (recipient_information), but that is optional.

A delivery follows a simple state machine:

The meaning of the states is as follows:

Note that a delivery's status can be modified via the API (via PUT ​/org​/{org-id}​/fulfillments​/deliveries/{delivery-id}​/status) but that it cannot be set to CANCELED that way. A delivery only get's canceled when the sales order that it belongs to gets canceled.

Introduction (Spec)

This documentation describes the high-level architecture of the enfore Staff & Access Rights API.

The enfore Staff & Access Rights API is provided by the enfore platform to allow management of staff members and their access rights without the need to use the client UI for this.

The exact set of modules and their capabilities will evolve over time, the initial API version will only support a very limited set of use cases.

Use cases

Domain model

The domain model of the staff members & access rights API consists of the core object types StaffMember, StaffAccessLevel and ApplicationAccessRights. A StaffMember is an employee of the organization. A StaffAccessLevel is an entity that can be granted access rights and that staff members can be assigned to. ApplicationAccessRights is the structure that holds the information what staff member and/or access level has which access rights.

Application Access Rights

The enfore platform manages application access rights on a "per application"-basis. The term "application" in the context of this API means "client application" such as "enforePOS". For this API, the application is always specified via a path parameter (in addition to the staff member/access level and the organization).

There are four distinct types of access rights:

1. "Dashboard widgets" grant access to specific widgets on the application dashboard.
2. "Dashboard sales channels" grant access to view data for a specific sales channel via the dashboard widgets.
3. "Application workflows" grant access to specific workflows in the application (a workflow usually equals a specific sidebar menu item)
4. "Application functions" grant access to specific functions of the application (a function is usually some action/operation that can be invoked as part of a workflow)

The granted rights for each of the four types are listed in the map fields of the ApplicationAccessRights structure. The keys of the dashboard_widgets, application_workflows, and application_functions maps are access right identifiers (see the application-specific documentation appendices for those). The keys for the dashboard_sales_channels map are sales channel identifiers and are not depending on the application. The values for all four of the maps ApplicationAccessRightAccessInfo objects holding the IDs of the staff members and/or access level that are granted the right.

For example, the following structure:

{
    "dashboard_widgets": {
        "top_products": {
            "everyone": true
        },
        "total_revenue": {
            "access_level": "X",
            "staff_members": [ "A", "B"]
        },
        "open_invoices": {
            "staff_members": [ "A" ]
        }
    },
    "dashboard_sales_channels": {
        "hamburg": {
            "access_level": "X",
            "staff_members": [ "A" ]
        },
        "berlin": {
            "access_level": "X",
            "staff_members": [ "B" ]
        }
    },
    "application_workflows": {
        "sales_register": {
            "access_level": "X",
            "staff_members": [ "A" ]
        },
        "inventory_list": {
            "staff_members": [ "B" ]
        }
    },
    "application_functions": {
        "void_lineitems": {
            "staff_members": [ "A" ]
        }
    }
}

Means that:

• everyone has access to
  • the dashboard widget "top_products"
• access level X has access to
  • the dashboard widget "total_revenue"
  • the dashboard sales channels "hamburg" and "berlin"
  • the application workflow "sales_register"
• staff member A has access to
  • the dashboard widgets "total_revenue" and "open_invoices"
  • the dashboard sales channel "hamburg"
  • the application workflow "sales_register"
  • the application function "void_lineitems"
• staff member B has access to
  • the dashboard widget "total_revenue"
  • the dashboard sales channel "berlin"
  • the application workflow "inventory_list"

Default access

When no ApplicationAccessRightAccessInfo is given for a specific right (i.e., when the key is missing from the map), a "default access" configuration is used.

For dashboard_widgets and dashboard_sales_channels, the default access configuration is "no access to anyone".

For application_workflows and application_functions, the default access configuratin is "access to every staff member".

Appendix A - Application rights for "enforePOS" application

The only application with access rights management currently is the enforePOS application. Its application-id is enforePOS.

Dashboard widgets

• Module "Sales"
  • n4_applications_enforePOS_module_N4SalesModule__total_revenue
  • n4_applications_enforePOS_module_N4SalesModule__top_sales_categories
  • n4_applications_enforePOS_module_N4SalesModule__top_staff
  • n4_applications_enforePOS_module_N4SalesModule__order_average
  • n4_applications_enforePOS_module_N4SalesModule__revenue_by_weekday
  • n4_applications_enforePOS_module_N4SalesModule__revenue_by_time_of_day
  • n4_applications_enforePOS_module_N4SalesModule__top_items
  • n4_applications_enforePOS_module_N4SalesModule__flop_items
  • n4_applications_enforePOS_module_N4SalesModule__revenue_by_sales_channel
  • n4_applications_enforePOS_module_N4SalesModule__top_payment_methods
  • n4_applications_enforePOS_module_N4SalesModule__payment_methods
  • n4_applications_enforePOS_module_N4SalesModule__tip
  • n4_applications_enforePOS_module_N4SalesModule__inhouse_vs_take_away
  • n4_applications_enforePOS_module_N4SalesModule__revenue_by_tax_rate
  • n4_applications_enforePOS_module_N4SalesModule__top_promotions
  • n4_applications_enforePOS_module_N4SalesModule__granted_discounts
  • n4_applications_enforePOS_module_N4SalesModule__refunds
  • n4_applications_enforePOS_module_N4SalesModule__most_returned
  • n4_applications_enforePOS_module_N4SalesModule__top_options
  • n4_applications_enforePOS_module_N4SalesModule__escrow
  • n4_applications_enforePOS_module_N4SalesModule__due_invoices
  • n4_applications_enforePOS_module_N4SalesModule__invoices
  • n4_applications_enforePOS_module_N4SalesModule__open_invoices
  • n4_applications_enforePOS_module_N4SalesModule__sales_vouchers
  • n4_applications_enforePOS_module_N4SalesModule__active_sales_vouchers
  • n4_applications_enforePOS_module_N4SalesModule__average_revenue_per_guest
  • n4_applications_enforePOS_module_N4ServiceModule__cancellation_reasons
  • n4_applications_enforePOS_module_N4ServiceModule__cancellations_by_service
  • n4_applications_enforePOS_module_N4ServiceModule__no_shows
  • n4_applications_enforePOS_module_N4ServiceModule__no_shows_over_time
  • n4_applications_enforePOS_module_N4ServiceModule__reservations_by_origin
  • n4_applications_enforePOS_module_N4ServiceModule__service_cancellations
  • n4_applications_enforePOS_module_N4ServiceModule__upcoming_reservations

Application workflows

• Module "Sales"
  • register_reports
  • sales_invoicing
  • sales_promotions
  • sales_rawMaterial
  • sales_register
  • sales_reports
  • sales_salesCategories
  • sales_salesChannel
  • sales_salesHistory
  • sales_salesItems
  • sales_salesSettings
• Module "Reservations"
  • service_activeReservation
  • service_assignments
  • service_peopleAndEquipment
  • service_reservationHistory
  • service_reservationManager
  • service_services
  • service_settings
  • service_shiftPlanning
• Module "Customers"
  • customer_active
  • customer_allCustomers
  • customer_customList
  • customer_important
  • customer_inactive
  • customer_marketing
  • customer_returning
  • customer_settings
• Module "Order Management"
  • orderManagement_activeOrders
  • orderManagement_orderAssembly
  • orderManagement_orderHistory
  • orderManagement_settings
• Module "Inventory"
  • inventory_list
  • inventory_locations
  • inventory_purchasing
  • inventory_reconciliations
  • inventory_settings
  • inventory_stockTrading
  • inventory_supplier
  • inventory_transfers
• Module "Deliveries"
  • deliveries_deliveries
  • deliveries_incommingDeliveries
  • deliveries_outgoingDeliveries
  • deliveries_settings
  • deliveries_transferOrders
• Module "Settings"
  • businessAccount_devices
  • businessAccount_info
  • businessAccount_istaff
  • businessAccount_settings
  • businessAccount_staffplanning
  • settings_userRights

Application functions

• Module "Sales"
  • sales_acceptExpiredSalesVouchers
  • sales_accountPayment
  • sales_assignments
  • sales_cash_abort_drawing
  • sales_cash_deposit_cash_supplier
  • sales_cash_deposit_location
  • sales_cash_deposit_pettyCash
  • sales_cash_deposit_bank_account
  • sales_cash_deposit_staff
  • sales_cash_deposit_vault
  • sales_cash_deposit_expense
  • sales_cash_drawing_cash_supplier
  • sales_cash_drawing_location
  • sales_cash_drawing_pettyCash
  • sales_cash_drawing_bank_account
  • sales_cash_drawing_expense
  • sales_cash_drawing_late_at_location
  • sales_cash_drawing_late
  • sales_cash_drawing_safebag
  • sales_cash_drawing_staff
  • sales_cash_drawing_tip
  • sales_cash_drawing_vault
  • sales_cash_min_max_exceeded
  • sales_cash_reconciliation_at_location
  • sales_cash_transaction_device
  • sales_cash_transaction_staff
  • sales_changeInvoicePayments
  • sales_changeSalesChannelPrice
  • sales_checkout
  • sales_ExternalPayment
  • sales_manualCardPayment
  • sales_mobilePayment
  • sales_negativeBooking
  • sales_noPayoutOnLowerCashBalance
  • sales_payLater
  • sales_release_used_cash_drawer
  • sales_register_history
  • sales_registerReports_current
  • sales_registerReports_history
  • sales_registerReports_location_cashVaults_history
  • sales_registerReports_location_pettyCash_current
  • sales_registerReports_location_pettyCash_history
  • sales_registerReports_location_safebags_current
  • sales_registerReports_location_safebags_history
  • sales_registerReports_settings
  • sales_registerReports_complete_drawer
  • sales_registerReports_force_complete_drawer
  • sales_registerReports_complete_location
  • sales_registerReports_complete_staff_member
  • sales_registerReports_complete_staff_member_deputy
  • sales_registerReports_force_complete_other_staff_member
  • sales_registerReports_device_current
  • sales_registerReports_device_history
  • sales_registerReports_location_cashLedger_current
  • sales_registerReports_location_cashLedger_history
  • sales_registerReports_location_cashVaults
  • sales_registerReports_location_report_current
  • sales_registerReports_location_report_history
  • sales_registerReports_management
  • sales_registerReports_management_devices
  • sales_registerReports_management_staffMembers
  • sales_registerReports_management_locations
  • sales_registerReports_management_cashLedgers
  • sales_registerReports_management_pettyCash
  • sales_registerReports_management_cashVaults
  • sales_registerReports_management_safebags
  • sales_registerReports_organisation
  • sales_registerReports_reopen (deprecated)
    • use sales_registerReports_reopen_device and functions_sales_registerReports_reopen_staff_member instead
  • sales_registerReports_reopen_device
  • sales_registerReports_reopen_staff_member
  • sales_registerReports_share (deprecated)
    • use sales_registerReports_email and sales_registerReports_print instead
  • sales_registerReports_email
  • sales_registerReports_print
  • sales_registerReports_staffMember_current
  • sales_registerReports_staffMember_history
  • sales_registerReports_start_drawer
  • sales_registerReports_start_location
  • sales_register_history (deprecated)
  • sales_release_own_cash_drawer_assignment
  • sales_salesReports_bySalesCategory
  • sales_salesReports_bySalesChannel
  • sales_salesReports_bySalesItem
  • sales_salesReports_byStaffMember
  • sales_salesReports_share (deprecated)
    • use sales_salesReports_print and sales_salesReports_email instead
  • sales_salesReports_print
  • sales_salesReports_email
  • sales_salesReports_total
  • sales_settings_fiscalmemory
  • sales_unpaidInvoicePayment
  • sales_userDefinedPriceDiscount (deprecated)
    • use sales_userDefinedDiscount and sales_userDefinedPrice instead
  • sales_userDefinedDiscount
  • sales_userDefinedPrice
  • sales_viewProductDetails
  • sales_voidPayment
  • sales_voidLineItem
  • sales_voidOrder
  • sales_delete_subOrdersAndInvoices
• Module "Customers"
  • customer_changeCreditLimit
  • customer_chargeAccount
  • customer_edit
  • customer_lockAccountCredit
  • customer_payoutAccount
  • customer_register_show_customer
  • customer_register_switch_customer
  • customer_customerList_edit
  • customer_customerList_addRemoveCustomer
• Module "Inventory"
  • inventory_manageInventory
• Module "Reservations"
  • service_activeReservations_occupancy
  • service_activeReservations_reservations
  • service_reservationManager_occupancy
  • service_reservationManager_reservations
  • service_reservations_force_checkout
• Module "Deliveries"
  • deliveries_goodsout_confirm
  • deliveries_goodsout_reject
  • deliveries_goodsout_start_picking
  • deliveries_goodsout_mark_as_picked
  • deliveries_goodsout_start_packing
  • deliveries_goodsout_mark_as_packed
  • deliveries_goodsout_mark_as_ready_for_pickup
  • deliveries_goodsout_mark_as_picked_up
  • deliveries_goodsout_mark_as_fulfilled
  • deliveries_goodsout_put_on_hold
  • deliveries_goodsout_release_on_hold
  • deliveries_goodsout_create_cancellation_request
  • deliveries_goodsout_withdraw_cancelation_request_self_created
  • deliveries_goodsout_withdraw_cancelation_request_by_others
  • deliveries_goodsout_withdraw_cancelation_request_business_process
  • deliveries_goodsout_confirm_cancelation_request_self_created
  • deliveries_goodsout_confirm_cancelation_request_by_others
  • deliveries_goodsout_confirm_cancelation_request_business_process
  • deliveries_goodsout_return_package_to_packed
  • deliveries_goodsout_reset_to_confirmed
  • deliveries_goodsout_reopen
  • deliveries_goodsout_release_all_goods_and_package_material
  • deliveries_goodsout_remove_package
  • deliveries_goodsout_cancel
  • deliveries_goodsin_start_review
  • deliveries_goodsin_mark_as_completed
  • deliveries_goodsin_reopen_delivery
  • deliveries_goodsin_reset_delivery
  • deliveries_goodsin_reject_delivery
  • deliveries_goodsin_create_delivery
  • deliveries_goodsin_item_add
  • deliveries_goodsin_item_delete
  • deliveries_goodsin_item_unknown_received_quantity
  • deliveries_goodsin_item_edit_delivery_note_quantity
  • deliveries_goodsin_item_edit_received_quantity
  • deliveries_goodsin_item_resolutions_add
  • deliveries_goodsin_item_resolutions_edit
  • deliveries_goodsin_item_resolutions_book
  • deliveries_goodsin_item_resolutions_adjust
  • deliveries_goodsin_item_resolutions_revert
  • deliveries_goodsin_mark_as_received
  • deliveries_goodsin_mark_as_reviewed
  • deliveries_goodsin_resolution_started
  • deliveries_goodsin_package_add
  • deliveries_goodsin_package_received
  • deliveries_goodsin_package_verified
  • deliveries_goodsin_package_not_received
  • deliveries_goodsin_package_reset_to_advised
  • deliveries_goodsin_package_reset_to_received

Inverse APIs

Inverse APIs are APIs that external integrators need to implement to enable specific functionality in the enfore platform.

For example, when an external pricing engine is to be used, integrators must implement the External Pricing Engine-API.

Document Creation Service (Spec)

Introduction

While the enfore platform provides a built-in capability to generate business documents that can then be printed or shared via email/SMS, it does not allow for an in-depth customization of such documents.

For merchants that want to have full control about the design and content of the generated documents, the enfore platform allows the inclusion of an external service for the creation of documents. That service is called a "Document Creation Service" (DCS) and must implement the "enfore Document Creation Service"-API.

The DCS must be configured for the organization and the configuration must specify for which business document types the service is to be used. This allows the service to only be used for those types of documents where custom design or content are necessary and frees the implementor of the service from the need to support all 30+ business document types.

While an instance of the custom document creation service must be available via the internet from the enfore Cloud, additional instances can be configured for each POS location. Those local instances are then used by the clients running at their POS location and are thus accessed via the local network. This enables full offline capability, provided the custom document creation service does work offline.

The following diagam shows the components and their relationships in a setup with local DCS instances:

Given this setup, the main use case is the creation and printing of an invoice document as part of the checkout of a sales order:

In the "receipt step" of the enforePOS checkout & payment flow, the enforePOS client requests the creation of the invoice document (1). The request will contain the invoice data (customer, amounts, line items, etc), the output format that the generated document is expected to have (e.g., A4 PDF) as well as context information (e.g., the organization, POS location and register the client is running on).

The DCS is expected to return the generated docment binary and, optionally, some "external data" (2). The external data will be persisted in the enfore platform together with the business document data so that it can later be passed back to the DCS in case a new document binary is needed.

This re-requesting of a document binary is needed because a) a document binary for a different output format may be needed and b) the enforePOS client will not upload the generated document binary to the enfore server as port of storing the invoice data (4).

The binary is not uploaded to avoid potential problems with limited network bandwith.

Note that, as the document is not uploaded to the enfore server, a later request to send the document via email (for example), requires a new document binary to be generated:

Design decisions

The current version of the DCS API has been designed around some decisions that have been made to be able to provide a useful API but not impose excessive requirements on the implementors and users of the API.

Directly returning document binary

The current DCS API requires the service to directly return the generated document binary in the response to the "createDocument" request.

While this requires the HTTP request/response to "wait" for the document generation, it avoids the need to implement a complete "job management" API with a "create job, poll status, download result" loop.

Document creation is expected to be done in less than 2 seconds and "parked" HTTP connections do not use up much resources, so the benefit of a simpler and easier to implement and use API should outweigh the drawbacks.

As a future extension, the requirement for the direct return of the document binary may be replaced with an option to return a "job ID" instead. Additional API for querying job status and downloading the binary will then need to be added.

Not uploading document binary

The enforePOS client will not upload the document binary to the enfore server platform. Instead, the enfore server platform will (re-)request the binary from the cloud-based DCS instance.

This is done as storing and uploading the document binaries on the client side imposes significant storage and bandwith requirements. Especially for the offline-capabale enforePOS2 clients, storing and uploading 100+ documents is not feasible.

Additionally, even if the design would include the document being uploaded from the client, the enfore server platform must be able to request documents directly from the DCS as the client will only invoke the DCS if the document is to be printed as part of the checkout. If the user chooses to not print the document during checkout, no document binary will be created as that would only slow down the checkout. Instead, the document will then be created only if explicitly requested via some action in the sales history.

No support for receipt output format

The current API does not define the parameters for the receipt output format. While the DCS will need to support creation of receipt printer documents at some point, this isn't necessary for the first roll-out as only page printers are used there.

Versioning

The DCS API supports versioning in two places:

• the actual OpenAPI endpoints
• the document data structures

Those versions will get increased separately, making them semi-independent. Note that they are not fully independent as specific versions of the document data structures may only be uable with specific versions of the OpenAPI endpoints.

The "createDocument" operation

For now, the DCS-API consists of just the "createDocument" operation. For this operation, a client executes a POST request against the DCS and provides the following information:

• Request ID
• Document Type Identifier
• Document Data
• Meta Data
• Locale
• Output Format
• (optional) External Data
• (optional) Duplicate Flag

The response is expected to be multipart/form-data consisting of one or two parts. The mandatory part named binary must contain the generated document binary and use content type application/octet-stream or application/pdf. Optionally, the DCS can provide an "external data" via a part named external_data using content type text/plain. The parts can be in any order, they must be identified by their Content-Disposition header field.

For example, a "createDocument" response may look like:

content-type: multipart/form-data; boundary="BOUNDARY"

--BOUNDARY
content-type: text/plain
content-disposition: form-data; name="external_data"

This is external data...
--BOUNDARY
content-type: application/pdf
content-disposition: form-data; name="binary"

<<< binary data of PDF >>>
--BOUNDARY--

Security considerations

Offloading the creation of business document binaries to an external service requires both the enforePOS clien/enfore server platform that calls the DCS as well as the DCS that is being called to trust the other part.

The enforePOS client/enfore server platform must ensure that it is receiving document binaries from a trusted DCS source as it is unable to verify the contents of the binary (e.g., PDF). Otherwise, the system may print documents stating information that is not true.

Similarly, the DCS must ensure it only creates document binaries for a trusted client (enforePOS client or enfore server platform) as otherwise it could be used to create documents for business operations that have not happened or documents that contain data different from what actually happened.

The exact means of establishing two-way trust will still need to be worked out. Options that have been mentioned are:

• client -> DCS
  • Use of client certificates
  • Use of authorization header
  • add cryptographic signature in application layer (i.e., part of request)
• DCS -> client
  • rely on HTTPS
  • add cryptographic signature in application layer (i.e., part of response)

Domain Model (Spec)

The domain model of the External Pricing-API consists of the core object types PricingEngineContext and PricingEngineResult. A PricingEngineContext is sent to the external pricing logic which is expected to return a PricingEngineResult.

Line items

Both PricingEngineContext and PricingEngineResult mainly consist of items. In case of the context, those are of type PricingEngineContextLineItem. For the result, the items are either PricingEngineResultItem or PricingEngineResultAdditionalItem objects.

Line item dependencies

In most cases, a line item is a stand alone item and fully describes the order position by itself. In some cases, though, a position is complex enough to need additional items to be expressed. Those items are not independent items but are depending on a "root item".

For example, consider a sales order at a burger restaurant:

Here, the Burger is a configurable BTO (built to order) product with a "base price" of € 8,00 and the specific sale includes the options Bacon, Extra Cheese, and Well done.

Line item dependency types

The enfore platform supports different types of line item dependencies.

OPTION

The most common line item dependency type is OPTION. An option represents a dynamic choice made by the user at runtime when adding a product an order.

Items of type OPTION are included when computing the line item total and are shown in the client UI and printed on business documents as sub-items for their main item.

DEPOSIT

For modelling deposits, the enfore platform uses the line item dependency type DEPOSIT. Deposits are configured on the product via the client UI and cannot be modified by the user at runtime when adding a product an order.

Items of type DEPOSIT are included when computing the line item total and are shown in the client UI and printed on business documents as sub-items for their main item.

CONTENT_COMPOSITION

For describing the contents of a sold item, the line item dependency type CONTENT_COMPOSITION can be used.

This dependency type is currently only usable by the external pricing logic, there is no way to create such items via the product configuration or client UI.

Items of type CONTENT_COMPOSITION are ignored when computing the line item total and are not shown in the client UI nor printed on the generic enfore documents.

Custom document templates may choose to display those items in addition (or even in place) of the main item. When the items are to be displayed in place of the main item, care must be taken to ensure that the combined prices of the CONTENT_COMPOSITION items match the price of the main item so that the overall price displayed stays the same. See the depdency typen PRICING_COMPOSITION for more information.

PRICING_COMPOSITION

For describing how the price of a line item was computed, the line item dependency type PRICING_COMPOSITION can be used.

This dependency type is currently only usable by the external pricing logic, there is no way to create such items via the product configuration or client UI.

Items of type PRICING_COMPOSITION are ignored when computing the line item total and are not shown in the client UI nor printed on the generic enfore documents.

Custom document templates may choose to display those items in place or in addition of the main item. As those items are used to visualize the price computation, care must be taken to ensure that the combined prices of the PRICING_COMPOSITION items match the price of the main item so that the overall price displayed stays the same.

Specifically, discounts applied to the main item must be present at the PRICING_COMPOSITION items as well.

For example, assume a main item for the product Box of flowers whose price is computed from the products Rose (2x per Box) and Tulip (5x per Box):

Increasing the quantity on the main item must also update the quantities on the PRICING_COMPOSITION items:

Discounts present on the PRICING_COMPOSITION items must be present on the main item as well:

Note that different discounts can be present for each PRICING_COMPOSITION item. The important thing is that all discounts from the sub items must be present on the main item as well:

Introduction (Spec)

The External Payment Method-API defines the endpoints that the enfore platform will invoke on an external server component when an external payment method is being used.

The API defines endpoints for:

• checking the availability status of the external payment method
• validating payment vouchers
• computing possible payments
• processing of payments and payouts

Types of external payment methods

The enfore platform supports three types of external payment methods:

• basic EPMs
• CUWO-based EPMs
• API-based EPMs

Basic EPMs are payment methods that do not have an actual integration with an external service, so in effect they can only be used to manually record a payment as "having been made via some external system" with no way for the enfore platform to validate this or to provide any user interface integration.

CUWO-based EPMs are backed by custom workflows, so when a payment or payout is to be performed using such an EPM, the enforePOS runtime will display the appropriate CUWO and that CUWO can perform the necessary user interaction. For more information on CUWO-based EPMs see the CUWO documentation

API-based EPMs are backed by an external service that must implement the API defined here. Whenever a payment or payout is to be performed using such an EPM, the enforePOS client will invoke the relevant endpoints of this API to process the payment/payout. Note that the API will not be directly invoked by the enforePOS client for technical reasons but that all invocations are routed through the enfore server backend.

Concepts

Availability check

Availability checks are only used for CUWO-based EPMs

The API provides the endpoint /org/{org-id}/status/ that is invoked by the enforePOS client for determining whether the external payment method is available.

For CUWO-based EPMs, this endpoint is invoked upon entering the payment flow UI to determine whether to enable the button for the EPM or not and what information to show there.

If the payment method reports that is it not available or when the status check fails (e.g., due to network error), the EPM is not available for selection by the user.

Payment vouchers & possible payments

Payment vouchers & possible payments are only supported by API-based EPMs

API-based EPMs support "payment vouchers". Payment vouchers are vouchers that can be translated into a payment. Payment vouchers are similar to discount coupons in that they have a monetary value and often (but not necessarly) have limitations/requirements that control when they can be used. For example a voucher might be defined as "2€ payment when bying 5 or more cans of beans".

The main difference between a payment voucher and a discount coupon is that a payment voucher does not reduce the invoiced amount but that, instead, it is used as a payment.

For example, assume a basket consisting of "10x cans of beans" where each can costs 5€. The line item/basket total would then be 50€. With a discount coupon of "2€ discount when bying 5 or more cans of beans", the line item/basket total would be reduced to 48€ and the user would receive an invoice with a total amount of 48€ and a "due amount" of 48€. With a payment voucher instead, the line item/basket total would stay at 50€ and the user would receive an invoice with a total amount of 50€, a 2€ payment, and a "due amount" of 48€.

During sales process

When the user presents a payment voucher during the sales process, the enforePOS runtime will use the EPM-API to validate it. The validation will only receive the voucher code and a payment context (POS location, device, customer, etc.) but not the full basket. Thus, it will not be able to validate any constraints like "when bying 5 or more of ..." that the voucher might have. The validation is to determine whether the voucher is valid "in general" but it cannot yet determine if it can actually be used.

Once the user chooses to start the check-out, the enfore system will invoke the API's "compute possible payments" endpoint. That endpoint receives all validated vouchers, the payment context, and the full basket. Based on that information, the external service is to compute what payments are actually possible.

Note that the computation of "possible payments" can also be configured to be done when no payment vouchers have been scanned. That way, payments can be generated based on additional information available only to the external service (e.g., vouchers activated via a mobile app).

After the "possible payments" have been computed, they are presented to the user as part of the checkout process. There, the user can check if the computed payments match his expectations and may deselect payments he does not want to perform or re-trigger computation (e.g., in case the first computation failed).

Once the user confirms the possible payments and enters the payment part of the checkout flow, the enfore system uses the "process payment" endpoints of the API to process the selected possible payments.

The following diagram shows how this fits into the UI flow for sales in the enforePOS register:

(*) Note that "processing a payment" may consist of multiple API calls

When voiding items

When voiding items from an invoice that was at least partially paid with payments returned from the "compute payments" API endpoint (that is, payments based on payment vouchers or some other configuration inherent to the EPM), it may be that the reason for those computed payments no longer exists. If that is the case, the customer must not receive the full payout amount. Instead, a part of or the full amount of the computed payment may need to be turned into a system-driven payout to offset the no-longer-valid payment.

For example, assume a customer did by "10x cans of beans" for 5€ each and used payment voucher woth 2€ with the limitation "when bying 5 or more cans of beans". The invoice total would be 50€ with 2€ paid via the voucher and 48€ paid by other means (let's assume cash for the sake of the example):

If the customer now returns all the cans for some reason, a credit memo for this would have a total of 50€ as that was the invoice amount. But the user should not receive a payout for the full 50€ as the would mean that he gained 2€ since he originally only paid 48€ from his own money.

Instead, the payment that resulted from the voucher must be offset by a special "offset payout" to reduce the remaining amount to be paid out to what the customer originally paid:

Note that it is not possible to simply revert the initial voucher payment. Doing so would just cause the original invoice to suddenly have an open due amount. And it would not do anything for the credit memo, whch would still need to be paid out in full.

It is also not possible to simply reduce the credit memo amount as that would imbalance the tax amounts of the invoice and the credit memo, causing a loss for the merchant.

In case of a partial void (e.g., customer returned only 4 or 6 cans), a decision must be made whether the voucher payment needs to be offset by an offset payout and to what amount.

For example, returning just 4 cans could mean no offset payout is necessary as the limitation of the voucher is still met. Returning 6 cans clearly causes the voucher limitation to no longer be met, but whether the full 2€ must be offset or just some part of the 2€ is a decision that depends on the voucher's conditions.

As the enfore platform cannot determine whether a void requires an offset payout and what the amount should be, the EPM API is invoked to let the EPM logic decide. This is done by invoking the "compute necessary offset payouts for void" endpoint. The EPM is expected to return the offset payouts that must be performed for the void. Those payouts will then be processed using the "grant payout" API endpoint like normal payouts with the addition of a reference to the original payment being passed as parameter. Additionally, the "compute necessary offset payouts for void" endpoint can add "external data" to the computed payouts that will also be passed as input to the "grant payout" endpoint.

The "compute necessary offset payouts for void" endpoint will not only receive the void basket but also the original sales basket items (including information about previously voided units) and the original EPM payments (including information about previously performed offset payouts). Note that any payments of the original invoice not performed via the EPM are not passed to the EPM for security and privacy reasons.

The following diagram shows how this fits into the UI flow for voiding an invoice that was at least partially paid by voucher payments via the enforePOS register:

(*) Note that "processing a payout" may consist of multiple API calls

Payment processing

In general, the enfore platform processes payments as a "payment request" that goes through the following steps:

• Started - newly create PR, payment amount has not been reserved or moved yet
• Authorized - payment amount has been reserved/approved (e.g., by a payment provider)
• Captured - payment amount has been granted/transferred to the merchant
• Booked - payment amount has been booked into the merchant's accounting system

Additionally, payment requests can "Fail" or become "Canceled".

Also note that not every payment method supports the distinction between "Authorized" and "Captured". For example, a basic cash payment does not have a "Authorization" stage but is immediately "Captured" when the customer has handed over the money.

Note that transitions from "Authorized" or "Captured" to "Canceled" only occur after a previous authorization/capture of money has been released/reverted. And that transitions from "Authorized" or "Captured" to "Failed" only occur after that release/reversal failed.

For the built-in payment methods, the enfore platform contains the logic to perform the operations necessary to transition the states of the payment/payout requests. For API-based external payment methods, that logic must be provided by the external service and exposed via the endpoints defined in the API:

• for payments
  • /org/{org-id}/external-payments/payment-processing/authorize-or-capture-payment
  • /org/{org-id}/external-payments/payment-processing/capture-payment
  • /org/{org-id}/external-payments/payment-processing/cancel-payment
• for payouts
  • /org/{org-id}/external-payments/payment-processing/revert-payment
  • /org/{org-id}/external-payments/payment-processing/grant-payout
  • /org/{org-id}/external-payments/payment-processing/cancel-payout

For payments, the possible activity flow looks like this:

For payouts, the flow is similar:

Note that the flows are almost identical to the ones defined for CUWO-based EPM with the exception that API-based EPMs do not define a "cancelled" result for the different operations. An operation can either succeed or fail, as there is no human interaction that could trigger a cancellation.

• External Loyalty Programs (Spec)
  • Requirements and Context
    • Loyalty Programs
    • How External Loyalty Programs services work
    • Integration API for ELP
  • Solution Outline
    • Diagram for sale interaction
    • Diagram for refund interaction
    • Discussion of individual steps
      • Verify ELP subscriptions and coupons
      • Calculate loyalty points for sales
      • Book loyalty points for sales
      • Revoke loyalty points for refunded sales
      • Reporting coupon usage

External Loyalty Programs (Spec)

To support loyalty programs managed as external service, the enfore platform provide "External Loyalty Programs" (in short: ELP). They are managed inside the platform as a new kind of Promotion.

This document describes the general workflows and how they are supported by the enfore platform.

Requirements and Context

Loyalty Programs

Loyalty Programs reward purchases and maybe other customer actions by giving benefits, most often expressed as "points" that can be collected by customers. The customer can redeem the points and get coupons, vouchers or goods in return, or he can use the points to pay orders by converting the points into a monetary value.
enforePOS allows all our customers to create Loyalty Programs as "Promotions". In these Loyalty Programs they can create rules how points are earned and other rules how these points can be converted into coupons or vouchers.
There are many existing loyalty programs outside where service providers (e.g. Payback) offer their services through their APIs and businesses have connected their IT backends to these services. The enfore platform defines an interface that allows to integrate these backend solutions in the enfore platform workflows, especially the enforePOS applciation.
The goal of this integration is to externalize all procedures that require an interaction with the loyalty program service provider, but store all relevant results from these actions in the enfore data objects (e.g. orders and invoices).

How External Loyalty Programs services work

In an external Loyalty Program a service provider like e.g. Payback offers merchants to manage customer accounts for them that collect points. The customers of the merchants register at the service provider and get a card from him. When a customer presents his card at any of the merchants that participates in the program, the customer can get "points" for his purchase. The points are submitted to the service provider and stored in the account maintained for this customer. The customer then can redeem his points at any merchant that participates in the program later.
An external program is more complex than the loyalty programs inside the enfore platform because more than two parties are involved here:

• the service provider
• the customer
• the merchant that grants the points
• the merchant where the points are redeemed

The service provider settles the points granted by a merchant with the points redeemed at the merchant in regular clearings for a fixed time range. Simply spoken, if a merchant granted more points than he redeemed in that time range, he has to pay something to the service provider. OTOH merchants with the opposite balance will receive money. This is important for the understanding of how the accounting for these points works.
When points are redeemed, because a customer used it to pay for a basket at a particular merchant, this merchant gets less money for his sale because the customer paid less. The clearing with the service provider will compensate him for that loss. In return the merchant who granted the redeemed points now can claim a revenue decrease for the original sale for that the points have been granted.
To make that process work, a merchant that grants points must not only tell the service provider how many points have been granted, but also for which sale. The service provider will keep that information and redeems points with a "first in, first out" policy. He will notify the merchant who granted the points when it is time to claim a revenue reduction and for which sale.
According to latest German jurisdiction, the point in time when the merchant can account for the revenue decrease is not the time of clearing, but the time of redemption, because the latter is the time where the customer experiences the reduction.
Sidestep: a revenue reduction can be claimed only if the loyalty program enables the customer to redeem points by paying with them or by getting a cashback. If the loyalty program only offers other non-monetary bonus, no revenue reduction is possible.

Integration API for ELP

The ELP integration in the enfore platform supports collection of points for External Loyalty Programs and payments using such points. It does not support other kinds of points redemption. In result, the integration API must support several functions:

• Verify ELP subscriptions
  Verification of subscription usually happens through scanning a code on an ELP subscription card and sending the identifier from that card to the service provider through the ELP API. In case of success the call may return contact data and status information about the member.
• Verify validity of ELP coupons (optional)
  Loyalty Programs might issue printed coupons that give extra points when presented, depending on the content of the basket. The ELP API allows to verify if presented coupons are valid. This functionality is optional for ELP that do not support coupons.
• Calculate loyalty points for sales
  Sales are as represented "baskets" of sales items. enfore uses the ELP API to calculate points for them. The API call input is a suitable abstraction of the basket together with the customer identifier and all coupon identifiers that have been collected.
• Book granted loyalty points on sales
  At a certain point in time the calculated points for a basket will be booked for the customer using an ELP API call.
• Revoke loyalty points on refunds (optional)
  In reverse to the booking of granted points, points can be revoked from the customer balance when the sale that yielded the points is refunded partially or in full. This functionality is optional for ELP that do not require to revoke points for refunds.
• Report usage of couponts (optional) When coupons are supported, all coupons that have been used for the final calculation stored in the created invoice must be reported as "used" so that the ELP can devalue them if necessary

Each API call is expected to either return a "success" or a "failure" result. The latter must be returned only if the call could not be executed for whatever reason, an empty result or a rejected verification are expected to be returned as a "success".
The execution of a payment using loyalty points and the retrieval of the points available for that is not part of the ELP API, it used the API for external payments. The configuration of the ELP must link to the EPM used for such payments.

Solution Outline

There are two workflows to discuss here: sale and refund. The latter is only about returns via invoice corrections (credit memos) here, not about returns as "minus bookings" in the register.

Diagram for sale interaction

The following picture shows a typical ELP interaction for sales in the enforePOS register:

(*) depending in the ELP configuration payments might be required before points are granted

Diagram for refund interaction

A typical return workflow:

Discussion of individual steps

Verify ELP subscriptions and coupons

ELP subscription cards and ELP coupons are usually registered with a scanner. For the enforePOS application this is different to other "external scan code" use cases as e.g. external coupons created by the enfore customer, as here we haven't imported objects beforehand to that the scan code could be resolved.
So the identification and acceptance needs to happen in a context where it is known that an ELP ID card or an ELP coupon shall be scanned. The context can be created in two ways:

• by the ELP by defining possible ranges for the identifiers in its configuration
• by enfore by having a dedicated button for scanning an ID card

Once a scanned card has been accepted by either method, the "verifySubscription" and "verifyCoupon" calls in the ELP API will be used to verify the input. The ELP API is expected to return a "success" even if the subscription or coupon could not be identified. In that case a status information in the result will report the details. A "failure" return value is expected only when the verification itself could not be done for whatever reason.
The enforePOS register must allow to scan the ID cards and coupons at any time, even in the checkout flow. Repeated scanning of different ID cards will be handled in a way that always the latest scan will win.
Some loyalty programs want the cashier to ask their customers if they are members. enforePOS will show a corresponding hint to the cashier if the ELP configuration requires that.
The call for the card verification optionally can return the number of points available and the points available for redemption.

Calculate loyalty points for sales

Once the pricing calculations for a basket have been finished, ELP loyalty points could be calculated too by using the "calculateBasket" call in the ELP API. For performance reasons we don't do this call after each change in the basket. By default enforePOS will do the call at least just before the checkout, but we can have more actions or flows where a call could be needed.
The call must return not only the calculated points, but also the coupons used for them.
As the result of that calculation does not influence the payment flow, we can do the final call in the background and only must make sure that we get the results before we create the invoice, as the final calculation result is stored in the created invoice. The resulting points will be booked in a separate call.
Usually the "calculateBasket" call gets the customer ELP ID as input, but it is also possible to do the call without that ("if you where subscribed ...").
When the basket gets checked out, the result of the final "calculateBasket" call is stored in the created invoice. We also store the time of the call in the result.
The calculation result is stored even if the call failed, so that the failure is documented. If the calculation failed because of problems with the ELP service, the stored data allows to catch up on this later.
The "calculateBasket" call can return ELP related information to be printed on invoice or receipt documents as textual data in a list of "AdditionalInvoiceInformation" objects.

Book loyalty points for sales

Points will be booked through the "grantPoints" call of the ELP API when the invoice got processed or paid completely, depending on the ELP configuration. This will add the granted points to the balance of the customer and it will also cause a financial penalty for the merchant that will be realized in the next settlement with the service provider (that is not subject to any business process in the enfore platform).
The result of the "grantPoints" call is stored in the "loyaltyProgramResults" of the invoice, together with the time of the call.
The result is stored even if the call failed, so that the failure is documented.
If the grant call failed because of problems with the ELP service, the stored data allows to catch up on this later.

Revoke loyalty points for refunded sales

If the ELP configuration asks for points revocations in case of refunds, the "revokeGrantedPoints" call in the ELP API will be used when the credit memo is processed by the enfore platform.
A points revocation will subtract these points from the balance of the customer and it will also cause a financial refund for the merchant that will be realized in the next settlement with the service provider (that is not subject to any business process in the enfore platform).
It's up to the ELP implementation to decide whether the revocation will actually be executed or the request will be ignored for whatever reason (points too old, balance is empty etc.). If the revocation request could be executed and led to a defined result, the call is expected to return a "success" result.
The result of the "revokeGrantedPoints" call is stored in the "loyaltyProgramResults" of the debit IncomeTransaction. We also store the time of the call in the result.
The result is stored even if the call failed, so that the failure is documented. If the revocation failed because of problems with the ELP service, the stored data allows to catch up on this later.

Reporting coupon usage

Coupons can give additional loyalty points to customers. ELP may support printed coupons as described here that are presented and scanned at the point of sale. The enfore platform will send them along the basket in the calculation calls. Other coupons might be activated by the customer using different means, e.g. an app on a phone that is issued by the ELP service provider and allows to activate "electronic" coupons on the customer's demand.
The calculation call in the ELP API is expected to return identifiers of all used coupons, the printed coupons as well as the electronic coupons. The enfore platform will store the whole list in its invoices and also reports them as used when the points are granted.
If the ELP is configured to expect granting of points to happen only if the invoice is paid, coupons will nevertheless be reported as "used" already when the invoice is processed. If the invoice is voided before it got paid, points will never be granted for that invoice and so the enfore platform will send a "restoreUsedCoupons" call to the ELP API that can restore the coupons, if the ELP supports this.

Introduction (Spec)

TODO

Introduction (Spec)

The External Contact Management-API defines the endpoints that the enfore platform will invoke on an external server component when an external contact management is enabled and the user performs specific actions.

The API defines endpoints for:

• resolving a scanned identifier to a contact
• determining what payment options a customer can use

Use cases

Resolve contact

The POST /org/{org-id}/external-contact-management/contacts/resolve is for determining the contact identified by a scanned contact identifier.

The endpoint will receive the scanned identifier, the purpose identifying what type of contact is expected and the usual context information (sales channel/location, device used, etc.). If the passed identifier matches a contact, the endpoint must return a "contact information" structure with data about the customer. As the API is being used when external customer management is enabled, the returned structure should be an AnonymousContactInformation or PlaceholderContactInformation.

Check available payment options

The POST /org/{org-id}/external-contact-management/customers/check-available-payment-options endpoint is used for determining what payment options are available to a customer.

The endpoint will receive information about the customer and the usual context information and is expected to return, for each payment option, whether it is enabled and up to what limit. The check currently only covers the pament options "later", "invoice", and "deferred invoicing", but that may be extended later if necessary.
